Wj-914-610 Portable K Q Span Large Span Arch Roof Roll Forming Machine

Product Description

Descriptions
K Span Roll Forming Machine
K-Span system mobile roll forming machines are capable of constructing arch buildings and roofs on site, with spans ranging from as narrow as 4m to as wide as 40m. There is no limitation on the length of the building or roof that can be produced.K-Span system arch roofs can be installed on masonry brick, concrete or steel structures, eliminating the need for a conventional roof support structure.K-Span system arch buildings and roofs can be adapted to fit existing infrastructure or be considered as a standalone solution for new projects.K-Span system arch buildings and roofs can be extended at any time after completion offering clients the flexibility to expand infrastructure as the need develops.
K Span Roll Forming Machine

Specification
Drive System	Electric
Power Device	30kw Diesel Generator
Electric Standard	380v, 50hz, 3 phase
Total Power	18.5kw
Forming Power	7.5kw
Cutting Power	4.0kw
Bending Power	4.0kw
Conical Power	3.0kw
Step of Rollers	13 Steps
Material of Rollers	45# Steel, quenched HRC 58-62
Material of Shafts	45# Steel, quenched HRC 58-62
Material of Cutting Blade	Cr12MoV Steel
Type of Cutting System	Hydraulic
Material of Bending Leaves	Stainless Steel
Forming Speed	15m/min
Bending Speed	13m/min
Seaming Speed	6-8m/min
Control System	PLC (Omron)
Uncoiler Capacity	About 6000kg

Why Choose Us
Company Profile
√. WADJAY factory has a complete set of machines and equipment for processing services.
√. The company is committed to controlling the entire production process and providing you with the best quality and after-sales service.
√. Professional operation management team with experienced engineering and technical personnel.
√. One of the global manufacturers of high quality and excellent customer service.
√. More than 10 years of machinery production experience.
√. The company's products are exported to more than 50 countries and regions around the world.


Packing & Delivery
FAQ
Q1: How long is the warranty?
A1: We guarantee a 18-month after-sale service. Any problem when using, call or mail us, we will advise on technically sound methods. If needed, we will provide free accessories.
Q2: Can I have my own customized product?
A2: Yes, your are welcome customized requirements for color, logo, design, package, carton mark, etc.
Q3: How can I get sample and how long will it take?
A3: Sample policy is different for different items. Please kindly contact us to get details.
Q4: What's the MOQ?
A4: MOQ is different for different items, please kindly contact us for confirming.
Q5: How do I pay for my purchase order?
A5: T/T, L/C at sight, Western Union, MoneyGram.
Q6: What is your terms of payment?
A6: For regular order, T/T 30% as deposit, and 70% before Shipment. We'll show you the photos of the products and packages before you pay the balance.
Q7: How about your delivery time?
A7: Generally, It will take about 35 days to send goods out. The specific delivery time depends on the items and the quantity of your order.
