Automated Fin Tube Production Line with Smart Controls
| US$8,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BW
Core Components
Motor
Key Selling Points
High Productivity
Base Tube Diameter Range
7~11mm; 12~32mm; 15~45mm
Outer Diameter of Finned Tube
25mm/64mm/77mm
Base Tube Material
Aluminum, Carbon Steel, Copper
Fin Material
0.3~0.45mm
Finned Tube Length
0-15m
Spindle Rotating Speed
80rpm, 100rpm, 120rpm
Transport Package
Wooden Case
Specification
Customized
Trademark
BANGWIN
Origin
China
Product Description
Product Description-Tool holder and tool holder body adopt advanced dual-circular-key structure, big torque withstanding, accurate and reliable displacement.
- Tool holder adopts split type design, convenient for blade debugging, cleaning & fixing.
- Blade spindle bushing adopts special taper sliding bearings brings max. bushing utilization.
- Universal joints and spindles are of spline linking; And coolant cooling tank is separate to main rolling machine.
- Special extruding blade design, high efficient, long blade life.
| SPECIFICATIONS OF EXTRUDED FIN TUBES | |
| Base tube material | carbon steel, stainless steel, copper |
| Base tube diameter range | Φ15~45mm |
| Fin material | aluminum or copper |
| Extruded fin thickness | 0.3~0.7mm |
| Extruded fin height | max. 16mm (aluminum) / 8mm (copper) |
| Max. OD of finned tube | Φ77mm (aluminum) / Φ50mm (copper) |
| Applicable fin pitch | FPI 7, FPI 8, FPI 9, FPI 10, FPI 11 |
| Max. fin tube length | 15m |
