Textile Machinery Drying Machine for Open Fabrics and Tubular Fabrics

Product Description

Introduction
The drying machine is used for drying cylinder and open-width fabric with three-layer belt. Because of circulating drying and run under different speed, the fabric could keep in loosen circumstance without any tension during the drying process.
We provide corresponding machine according to different types of fabric to meet your requirements totally.
Based on the different width of belt, we could supply different models as following:
FSHG-2000mm/2400mm/2800mm/3200mm(standard)/3600 mm
Based on the different heat sources, we could supply the following models with six heating methods:
1. Steam (0.8MPa)
2. Steam (2.8MPa)
3. Heat conduction oil
4.Gas (direct combustion)
5. Gas (indirectly) 6. Biofuels
Our machines are equipped with conveyor belt made of Teflon material, it could bear high temperature and not pollute the fabric with non-staining.

Design & Drawing
Design, drawing and manufacture according to customer's OEM purchase order.
Typical Products Information Basic Info & Technical Data

Model	FSHG2800
Name	Relax Dryer
Application	Drying the fabric,eliminating exceeding water and achieving the natural moisture content of the fabric
Suitable Fabric	Knitted and Woven Fabric
Layout	Reference SH30-N4 layout
Max. Working Width	2400mm
Machine Speed	0-50m/min
Chamber Nos	4 Sets
Power Supply	380V·3P·50HZ
Weight of Machine	≈24.5T
Working Type	Three-layer net belt cycling
Net Belt Type	Glass fiber with PTFE coated
Driving Type for net belt	PLC+Inverter control
Heat-setting Type	Natural Gas heating hot air circulating
Max Drying Temperature	160ºC
Temp. control type	Automatically regulate two chambers temperature as one section
Length of Chamber	2.1M
Thickness of Insulation Board	105mm
Machine Dimension	L=12500mm W=4500mm H=3400mm

Advantage: We possess the upgrade and design ability with our professional technical team, your customized design could be changed into drawing. With advanced technology and best quality, we make sure that you can get satisfied products based on our pleasant cooperation.
Payment Terms
Payment Conditions: 30% down payment by T/T and the balance payment should be T/T or in irrevocable L/C at sight.
Delivery time:30-60 days from the date of receiving down payment. All payment should be received before delivery in China.

Any questions and requirments,contact us now!
