Vmc800 3/4/5axis CNC Machining Milling Machine with 850mm 8000rpm

Vmc800 3/4/5axis CNC Machining Milling Machine with 850mm 8000rpm

US$35,000.00-39,800.00 1 Piece (MOQ)

Basic Info.

Model NO.
GEEPRO
Structure
Vertical
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
0.003
Certification
GS, CE, ISO 9001
Condition
New
Warranty
12months
Voltage
220V/380V/400V or Customized
After Service
on-Site Installation
Tools Number
24 or 30atc
Transport Package
Wooden Package
Trademark
GEEPRO
Origin
China
HS Code
84571010
Production Capacity
300-500PCS/Year

Product Description



Specification List for:
Vertical machine center
3/4/5 Axis Gantry/Vertical/Horizontal Machining Center CNC Milling Machine
STANDARD ITEM
Standard configuration includes Fanuc Control ( Fanuc 0i-MF with package 5), Fanuc βmotors for 3 axis and Spindle, Vertical Disc Type Magazine with 24-Tools, BT40-8000 RPM Spindle, 3 Axis linear guide rail, Full metal guarding.

Main Specifications of EM800A CNC Machining Milling Machine
EM800A S.A.E. METRIC
Travel
X Axis 32" 800 mm
Y Axis 20" 500 mm
Z Axis 20" 500 mm
Spindle Nose to Table 6"-26" 150-650 mm
Spindle Center to Column Guideway 22" 550 mm
Table
Length 40" 1000 mm
Width 20" 500 mm
T-Slot Width 0.7" 18 mm
T-Slot Center Distance 4" 90 mm
Number of Std T-Slots 5 5
Table Loading capacity 882 LB 400 Kg
Table to the Ground 36" 900 mm
Spindle
Max Rating (10/15) hp (7.5/11) Kw
Max Speed 8000 rpm 8000 rpm
Max Torque 54 ft-lb 72 Nm
Drive Mode Synchronous Belt Drive
Taper/Specification ISO 7/24Taper NO.40
Feed Rate
Rapids on X/Y/Z 1890/1890/1890 IPM 48/48/48 m/min
Max Cutting 393.7 IPM 1-10000 mm/min
Min Feed Rate 0.0000394'' 0.001 mm
Axis Motors
Drive Mode for X\Y\Z Direct Inline Drive
Servo Motor Speed for X\Y\Z 3000 rpm
Diameter of Ball Screw for X\Y\Z ø1.6" ø40 mm
Ball Screw Pitch for X\Y\Z 0.6" 16 mm
ATC
Tool Magazine Vertical Disc Type with Manipulator
Capacity 24-Tools
Tool Shank BT-40
Shank Bolt P-40T( 45°)
Max Tool Diameter(full) ø3.1" ø80 mm
Max Tool Diameter (no adjacent tools) ø5.9" ø150 mm
Max Tool length 11.8" 300 mm
Max Tool Weight 18 LBS 8 Kg
Tool-to-Tool Changing Time 2.5 secs 2.5 secs
Dimension & Power Capacity
Machine Weight 11023 LBS 5000 Kg
Machine Height 101" 2550 mm
Machine Area (Length*Width) 99"*93" 2500 mm*2350 mm
CP 20 KVA
Precision
Positioning Accuracy 0.000197" 0.005 mm
Repeated Positioning Accuracy 0.000118" 0.003 mm

MAIN PARTS SUPPLIERS
PART NAME SPECIFICATION BRAND
Control FANUC-0iMF FANUC
Spindle Motor ΒiI8/12000 FANUC
Servo Motor for X/Y/Z βisC12/βisC12/βis22B FANUC
X/Y/Z Axis Linear Ball Guide Rail 35mm/35mm/35mm PMI/HIWIN/REXROTH
(P class)
X/Y/Z Axis Ball Screw ø40mm/ø40mm/ø40mm HIWIN/PMI (C3 class)
Spindle BT40-140 KENTURN
Tool Magazine BT40-24T OKADA
Cam Technology DEX
Approach Switch Omron
Tool Arm I-Ta
Magazine Motor Taiwan Gong Ji
Unclamping Cylinder HAOCHENG
Coupling Shaft REACH
Heat Exchanger DIORT
Electronic Components SCHNEIDER/OMRON
The power line and encoder line German LEONI
Cutting Fluid Bump STAIRS
Bearing for 3 axis BST30*62 NTN/NSK (P4 Class)
Extensible Cover HONGWANG
Lubrication Device BAOTN
Pneumatic Unit SMC/AIR.TAC
Coolant Pipe Bear 20 Bar
Assembling Bolt Taiwan Brand

OTHER CNC LATHE MACHINE WHAT WE CAN SUPPLY .
Also Focus on Laser Sheet Metal&Pipe Cutting Machine For Sale
1.Three axis line rail: X / Y-axis ball rail line, Z-axis roller rail line, less friction, shortening the movement time, improving the efficiency; meanwhile, high precision processing can be completed by the excellent repeating positioning accuracy. 2.Z-axis drive without counterweight: Z-axis with brake type servo motors, non-counterweight design, for batch processing of high-speed drilling and tapping parts. 3.Three-axis direct-type drive design: Three-axis motor and screw with direct-type drive design, no noise from the belt or gear without backlash and vibration problems, three-axes rapid movement up to 48m / min, greatly saving the non-processing time. Application:
Suitable for: telecommunications,medical equipment,automobile parts,molds,3C products processing
