Hy 120 Industrial GMP Standard Laboratory Lab Decanter Centrifuge

Product Description

Product Description HY 120 Industrial GMP Standard Laboratory Lab Decanter Centrifuge
HY Sedimentation Centrifuge is a horizontal, continuously working and continuously spiral discharging sedimentation centrifuge. It is used in a variety or industries for separating all kinds of solid liquid suspension, defecating liquid phase with graded rains, and dehydrating sludge.This lab decanter centrifuge is specially designed for laboratory two-phase separation process , widely reduce human work . They are mainly used for small batch continuous processing operations from 10L/H to 200L/H.
Product Parameters

Model	HY80	HY120
Bowl Dia	80mm	120mm
Cone angle :	5º	5º
Inner diameter of the feeding pipeline :	12 mm	12 mm
Rotation speed	10000r/min	8000r/min
Capacity :	20-200 L/H	50-400 L/H
Ratio (L:D)	3.85	3.85
Motor power	8 KW 380V/220V	5.5 KW 380V
Max separation force :	4600	4400
Weight	160kg	360kg
Outline size :	950*650*550mm	1150*750*650mm
Supply	Electronic control box with Siemens inverter . Siemens touch screen

Application Koen decanter centrifuges of common models (as listed in the table of technical parameters) are applied to oil drilling solids control system and drilling waste management. In addition, Koen centrifuges of other models (including those in the following table) can also be widely used in the following industries:
Environmental Protection Industry
1. Thickening and dewatering of various sludge in municipal sewage treatment plants
2. City tap water sludge dewatering and city domestic sludge dewatering
3. Printing and dyeing wastewater separation
4. Paper-making wastewater separation
5.Desulfurization waste water in power plants
6. Ceramics wastewater separation
7. Tannery sludge dewatering
8. Mine stone wastewater
9. Coal-washing wastewater
10. Oil drilling mud separation
11. Textile wastewater
12. Electroplating wastewater
13. Integrated wastewater in pharmaceutical factories
Chemical Industry
1. PVC resin dewatering
2. ABS resin dewatering
3. Classified dewatering of non-metallic mine clay granularity
4. Fuel dewatering
5. Chemical fiber
6. Tar
Food Industry
1. Soy protein separation
2. Starch dewatering
3. Vegetable oil separation
4. Deslagging of fruit juice beverages
5. Peanut protein separation
6. Dewatering of distillers' grains
7. Cane sugar deslagging
8. Breeding industry
9. Butchery
10. Industrial wastewater in breweries
Pharmaceutical Industry
1. Separation of dregs extracted from traditional Chinese medicines
2. Saccharomycetes' corpse treatment
Other Industries
1. Recycling of paint powder
2. Separation of calcium sulfate in concrete admixtures
3. Recycling of plastics' crushed aggregates
4. Kaolin classification
5. Treatment of livestock' faeces
Notes:★ The actual processing capacity depends on the particle size and the specific application
All contact material can made by SS304 ,SS316L , duplex steel .
And the machine surface can be painted or full stainless steel . depend on customized
