Mini Drilling and Milling Machine 13mm Drilling Capacity Dm130
| US$375.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DM130
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
3
Hole Diameter
13mm
Automatic Grade
Semiautomatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Colour:as Customers′ Require
Logo as Customers′ Require
Transport Package
Wood Case
Specification
ISO9001-2000 CE TUV
Trademark
white eagle
Origin
Made in China
Production Capacity
1000 PCS/Month
Product Description
Specification| Model | DM130 |
| Max. Drilling capacity | 13mm |
| Max. End milling capacity | 16mm |
| Max. Face milling capacity | 30mm |
| Spindle speed (vairable) | 100-2250rpm |
| Spindle taper | MT3 |
| Spindle stroke | 180mm |
| Distance between spindle nose to table | 280mm |
| Distance between spindle to column | 170mm |
| Working table size | 390x92mm |
| Travel of worktable (Y) | 228mm |
| Travel of worktable (X) | 100mm |
| Swivel of headstock | ±45° |
| T-slots | 2x12mm |
| Motor power(DC) | 400W |
| Net weight | 52kg |
2.Machine Photo:
