Surface Grinding Machine for Flat Grinding

Product Description

The hydraulic system of MY3270 hydraulic surface grinder is composed of a set of motor quantitative pumps. The maximum flow of the pump is 18L/min, the motor power is 4KW, the working pressure of the pump can reach 3Mpa, and the system pressure is adjusted by the relief valve. The main mechanical valve of the system is a special valve for grinders, which is divided into two parts, mechanical reversing control and throttling speed control. The throttling speed control part also has an unloading function, which can realize the start and stop of the workbench. This valve also has a buffer adjustment function. The machine tool has the characteristics of easy operation, flexible and reliable, no vibration, stable precision, good thermal stability, low noise, and easy maintenance. Machine Parameters

Parameters
Worktable size	(mm) L*W	700x300
Longitudinal travel of worktable	mm	720
Horizontal travel of worktable	mm	340
Grinding head vertical movetion	mm	500
lVertical feeding handwheel accuracy	mm	0.01mm/Gri2mm/Circle
l Horizontal feeding handwheel accuracy	mm	0.02mm/Grid 4mm/Circle
TWorktable T slot	mm	14x1
Grindhead spindle speed	r/min	1450
rGrindhead spindle motor	kw	4
Cooling motor power	kw	0.04
Oil pressure motor	kw	1.5
Power supply	Hz	50
Grindwheel size	mm	350x30x127
tNet weight	kg	1500
eMachine dimension	L*W*H	1.80x1.65x1.90

Machine Feature ★ Machine structure is mechanical ,make the machine stable quality,easy to maintain
★ Workpiece fixture is simple structure to supply good capacity.
★ Spindle and stroke use inverters to control, have good precision.
★ Stronge dual guide rails support to supply parallel stroke moving.Make machine have long lifetime.
★ The machine have mechanical Zero stop---set finished size , when size is the set size ,machine would stop working.
★ Time honing ----set time , time go off ,machine stop.
★ With several steps with honing tools, could get 0.001mm roundness,straightness would be 0.001mm,Size accuracy could be in 0.005mm
FAQ
Q 1. What products is this honing machine mainly used for?
It is mainly used for workpieces with bore diameter 40-100mm and working depth less than 300mm, and light workpieces such as connecting rods, bushings, gears, oil nozzles, oil pumps and hydraulic parts.
Q 2. What materials can be processed by this honing machine?
This honing machine uses our company's honing tools to process various workpieces. For various workpiece materials, we have diamond, cubic boron nitride, aluminum oxide, silicon carbide and other materials for grinding various workpiece materials.
Q 3. What should users do if they don't understand the honing process?
We will provide you with professional honing solutions for various products. We have served thousands of customers and have rich honing experience as well as rich international trade experience.
If you report problems using pictures and videos, we will provide you with solutions, video explanations, or video conferences to answer your questions.
Q 4. What about the shipping method and payment?
Our company has equipment and tools in stock for a long time. If the tools needed for your honing project are in stock, we can arrange delivery within 15 days. If out of stock, the total delivery time is 1 month.
Our company is a professional trading company providing international trade services, generally based on bank transfer, but also accepts letter of credit, personal transfer and other channels.
Q 5. How to set your company's operating hours?
Our company works and services according to the client's schedule. International trading business has professional knowledge and can quickly provide you with answers and services. You can use wahtsapp, wechat, email, etc. to communicate.
