Special for Petrochemical Industry Oil-Free VSD Magnetic Levitation Centrifugal Blower

Product Description

ENERGY-SAVING I ENVIRONMENTALLY FRIENDLY
HIGH AND NEW TECHNOLOGY I LOW COST I LOW NOISE NOTE: 1.The capacity is measured at 1atm/20/humidity 65%/density 1.2ka/m' , under the rated pressure of each model, the capacity adjustment range is 45~100%. 2. The machines used in harsh working conditions such as high temperature, high humidity, high cold, and high dust are non-standard models. 3. If the appearance and specififications are improved, the manufacturer has the fifinal right of interpretation.

Model	Power	Pressure	Capacity	Dimension	Weight
	KW	KPA	M3/MIN	W xD x H(MM)	KG
SCR75CB	50	40-90	30-60	1800*900*1500	900
SCR100CB	75	40-90	45-90	1800*900*1500	1100
SCR125CB	100	40-90	60-120	2000*1300*1800	1400
SCR200CB	150	40-150	65-195	2000*1300*1800	1700
SCR250CB	200	40-150	85-260	2500*1550*2050	2100
SCR300CB	240	40-150	102-310	2500*1550*2050	2400
Remark:	The capacity is measured at 1ATM/20°C/humidity 65%/density 1.2KG/M3, from the inlet of blower.

Service System
Free guidance on installation, commissioning, training
Response time: fast response within 2 hours.
Fast Troubleshooting.
Regular accessories shipped within 24 hours.
Regular return visits annually.
Free upgrade of equipment control system and operation software
SCR MAGNETIC LEVITAITON PRODUCTS
01-Japanese technology
Originated from Japanese technology, globafluid technology brand that started in 1926.
02-Core technology
Mastered the core technology of maglevcentrifugation and alwavs be at the forefrontof technology.
03-Craftsman spirit
Japanese craftsman spirit is world-renownedTovota-stvle lean production mode and qualitycontrol svstem.
04-Innovation and Iteration
Magnetic suspension bearing controtechnology and high-strength AL7075 aviationaluminum alloy technology are continuouslydeveloped.
05-Reasonable price
Sino-Japanese joint venture factory, localization authorization of core components.
06-Delivery on time
Intelligent factory, Using PLM, ERP, MES soft-ware.
Visualization management in manufacturing.
07-Complete range of products
Maglev 50kw-355kw stable product qualitysupport non-standard customization/industrycustomization.
08-Excellent after-sales service
The factory repairs the equipment and theservice cost is low.
09-Flexible cooperation
Support for distributor,EMC,energy-savingrenovation.
