Portable Electric Crochet Machine for Fancy Yarn

Product Description

Portable Electric Crochet Machine for Fancy Yarn
Product Description
VG-980 Crochet Machine
VG-980 model is a traditional high speed fancy yarn crochet knitting machine, first kints cloth with warp and weft yarn, then cuts the warp yarn to form the final yarn.otherwise it kints warp and weft yarn the straightly kit belt yarn.
VG-980 machine is suitable to knit various kind of yarns,both natural fibers(wool,silk,cotton, linen,etc) and synthetic fibers(polyester,acrylic etc)This entire material can de dyed before of after knitting,in accordance with the requirements.The characteristic of the patter yarn is the core yarn knitted into ring and the weft one used as its mattress.The finished yarn is of flat shape.
Features:
1.The patent structure increases the capacity about more 2~7 times than the old type,without widening the operation width.
2.The newly designed cam lowers the noise and extends the machine lifetime.
3.The optimized structure of the machine lengthens the further of the yarn and fasten the futher making the further being not falling off,even if intentional ly pulled by hand.

VG-980B Crochet Knitting Machine
VG-980B type crochet machine is a new type of crochet machine developed by our company on the basis of extensive absorption of customer experience and similar models. It is an upgraded model of VG-980 type crochet machine in our company and has obtained the national patent. Can greatly increase the speed and output of the whole machine without changing the width of the whole machine.
The advantages of the general 980 are as follows:
·Using servo motor weft feeding, weft feeding speed is higher, more accurate;
·Use touch screen to set process parameters, the replacement process is more convenient and flexible;
·The key parts are imported high quality bearings, the precision is higher, the production speed is higher, and the output is increased more significantly.

Product Parameters

Model	VG-980	VG-980B
Operational width	762mm	762mm
Gauge needle per inch	15G,18G,20G	10G,15G
Weft density range	5~20s/cm	5~20s/cm
Main shaft speed	1200r/min	1800r/min
The girth of rack frame	170cm	170cm
Full power	1.56KW	2.31KW
Yarn creel count	260	260
Yarn creel distance	200mm	200mm
Shape size (length × width × height)	Main machine: 1750 × 1950 × 1750 (mm) Winding section: 2300 × 2790 × 2400(mm) Yarn frame(1):2100 × 1880 × 2750(mm)

Company Profile
Jiangsu New Victor Industrial Co., Ltd. is a machinery equipment manufacturing enterprise integrating product research and development, manufacturing, and domestic and international independent marketing. Stock abbreviation: Xinzeqi, stock code: 873713.
Over the years, the company has adhered to a strategy of leading technology, continuously researching and developing and improving products according to market demand. The company focuses on its core business, deeply cultivates the segmented market of company products, continuously improves product and service quality, and builds the company's brand. The company has established a research and development center, formed a professional technical research and development team, and purchased advanced metal processing equipment. The company has passed ISO9001 quality system certification, integration of two management systems certification, and CE certification for product export. The company owns more than 70 independent research and development product patents and adds new patents every year.
The company has been awarded honors such as "National Special New Small Giant Enterprise", "Jiangsu Province High-tech Enterprise", "Jiangsu Province Special New Small Giant Enterprise", "Jiangsu Private Technology Enterprise", "Jiangsu Enterprise Technology Center", "China Textile Industry Association Special New Small Giant Enterprise", "Suzhou Gazelle Plan Candidate Enterprise", "Zhangjiagang Harmonious Labor Relations Enterprise", "Zhangjiagang Civilized Unit", etc. In addition to selling products in the domestic market, the company also exports to Eastern Europe, Africa, the Middle East, Southeast Asia, South America, and other countries.
Textile machinery, mainly including: crochet machines, snarl machines, fancy twisting machines, etc. The equipment is mainly used in the field of fancy yarn spinning and can produce hundreds of different three-dimensional styles of fancy yarns such as slub yarns, ribbon yarns, loop yarns, plush yarns, jet yarns, and snarl yarns, creating new fashion elements for garments, sweaters, and other textiles. The company is a leading enterprise in the domestic fancy yarn spinning machinery industry, and its products rank among the top in the domestic market share. The company's crochet machine was awarded the "Jiangsu Province Quality Credit Product" in 2006, the VFG-300 high-speed high-elastic filament machine was recognized as a high-tech product by Jiangsu Province in 2010, the XXNE200 high-speed snarl machine won the Silver Award for Industrial Design Products in Suzhou in 2019, and the XHND104 fancy yarn twisting machine won the Gold Award for Industrial Design Products in Suzhou in 2020.
After Sales Service
Pre-sale service
1. We can provide machine running videos for reference
2. We will recommend the most suitable equipment according to the needs of customers
3. We can provide the layout of the factory
4. We welcome customers to visit our factory, we can show you the running machine in China.
After-sales service
1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly
2.When you finish the Preparation conditions, Our fast and professional aftersales service engineer team will go to your factory
to install the machine, give you the operating manual, And train your employee until they can operate the machine well.
3.We provide one year warranty and life-long technical support.
4.Well-trained & experienced staff are to answer all your inquiries in English and Chinese
5 .24 hours for engineer response.
6.Your business relationship with us will be confidential to any third party.
7. We offer one year's supply of spare parts free of charge
Quality ControlWe have the single quality department, that make sure the material of the raw materials is good, and ensure the machine running smoothly.

FAQ
Are you a trading company or a manufactory?
We are a manufactory with 30 years experience, we supply the factory price with good quality, welcome to visit !
Do you have reference project?
We have reference project in most countries, If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory. And you are always welcome to come to visit our company, and see the machine running in our factory, we can pick you up from the station near our city. Contact our foreign sale team you can get video of our reference running machine.
Do you have agent and after-service stations?
So far we have agent in the middle east, Ethiopia, Singapore, South America. welcome to join us!
When can I get my machine after I paid?
Normally production time is around 30days, the exactly depend on what kind of machine you order. The shipping time is based on your destination port.
How long time for installation?
According your machines order, we will send one or two engineers to your plant, it will take about 7 days.
How about the spare parts?
We will send one year enough easy broken spare parts together with the machines, shipping together.
Do you have any certificate?
We have CE, ISO, SGS certification
Do you provide customized service?
We can design the machines according your requirements.
What's your guarantee or the warranty of the quality if we buy your machines?
We offer you high quality machines with 1 year guarantee and supply life-long technical support.
