30kg/Cycle Small Scale Stainless Steel Homogenizer Styrene Acrylic Resin Homogenizer

Product Description

High shear mixer for 220V 50Hz 1P AC voltage
30kg/cycle small scale stainless steel homogenizer styrene acrylic resin homogenizer
For the manufacturing of pharmacy, daily chemicals and food & beverage industry, especially cosmetic industry such as lipstick, facial cream, lotions, washing detergent, hand sanitizer and ointment.
To dispersing, shearing and cutting force in working load to get uniformly homogenizing and thoroughly emulsifying.
Installed on existing stainless-steel tank, vessel, IBC tote, plastic drum and barrels.
Main parts included in the high shear mixer / homogenizer
1. the driving motor for satisfactory operation under 220V 50hz
2. the mounting flange for easy assembly on existing tanks
3. the support shafts for working head and driving motor
4. a down thrust propeller on the main rotation shaft
5. the rotation shaft to hold the propeller and rotor
6. the rotor stator assembly (working head)
1HP 0.75KWhigh shear mixer specification

Model	TRS-0.75	TRS-1.1	TRS-1.5	TRS-2.2	High shear mixer sketch dimension drawing
Voltage	220V 1Phase AC
Mounting	Top mounting
Working mode	Batch type
Wet material	Stainless steel 304 / 316L
Motor poles	2
Speed	Synchronous RPM 3000
Protection	IP55 weatherproof enclosures
Motor power	1HP	1.5HP	2HP	3HP
Suitable for	10~30L	10~40L	20~70L	50~100L
L	400
M	165
P	200
D	88
D1	140
Over length	655

Offer high shear mixer from 0.75kw to max 22kw All dimensions except those clearly marked are measured in millimeters Suitable for both low and high viscosity fluid like water, milk, oil, gel, cream, water power mixture. Users can choose from B5 flange mounted motor or B35 foot cum flanged motors. For alcohol based flammable mixture, please choose explosion-proof motor first Stainless steel 304 and stainless steel 316L materials are both availableWare part
Using shaft sleeve that is made from mineral fiber and epoxy resin. Compared with ordinary graphite bushing, it has better wear resistance, better lubricity less expansion coefficient and longer service life.
Please contact our online service for more high shear mixer specification and technical details.
Hhe high shear mixer is about 40~45kg after packing. The freight listed on this site may not correct.
You can get the latest sea freight for this 1HP small scale high shear mixer from our sales team directly.
For air transport for high shear mixer, 0.75kw high shear mixer is also ok. the air freight of this 1HP high shear homogenizer will be a little higher thant its sea freight.
offer WRL-70 WRL-80 WRL-90 WRL-100 WRL-120 WRL-140 WRL-160 WRL-180 WRL-200 high shear homogenizer mixer for batch homogenizing
