CE 1000-1500kg/H Woodworking Biomass Pine Oak Beech Wood Sawdust Pellet Making Machine Press Manufacturer Production Line

Product Description

1000-1500kg/H CE Factory Wood Pellet Production Line Manufacturer Biomass Wood Sawdust Pellet Making Line Wood Pellet Mill Wood Pellets Machine Price Product Description
Introduction of Wood Pellet Mill/ Pellet Machine Price:
1.Ring die wood pellet mill is widely used in compacting of wood, straw, other biomass sources into pellet.Capacity ranges from 1T to 10T per hour
wood pellet production line
2.Adopt high-precision gear of pellet machcine drive advanced flexible coupling, for high productive efficiency;
3.Main driving adopt imported bearing, NSK oil seal and Siemens motor; pellet machine price
4.Frequency converter control feeder flow, full stainless steel of cover and chute.
5.Ring die pellet mill generate less wear and tear when pelletizing, and it is more energy efficient than the flat die pellet mill,
so, ring die pellet mills are adopted in most large scale pellet production lines.
Deatails of Pellet Machine :
Wood Pellet Production Line Pellet Mchine Price
Customer Feeback

Product Parameters
Technical Parameter of Wood Pellet Mill/Wod Pellet Machine

Model	MainPower(KW)	Capacity(t/h)	Feeding Power(KW)	Conditioner Power (KW)	Die Diameter(mm)
LH- 320	37	0.2-0.3	1.5	2.2	320
LH- 350	55	0.5-0.7	1.5	3	350
LH- 420	90	0.8-1.2	2.2	5.5	420
LH- 480	90	1.0-1.3	2.2	5.5	480
LH- 508	132	1.7-2.2	2.2	5.5	508
LH- 558	160	2.0-2.5	2.2	5.5	572
LH- 678	185	2.5-3.5	3	11	678
LH- 768	250	4.0-5.5	4	18.5	768

Detailed Photos
Raw material for making fuel pellet:
Sawdust, wood shavings, rice husk, wheat straw, cotton stalk, sunflower stalk, crop stalk, cottonseed skins, biomass wastes, forestry wastes, and many other wastes or solid powder materials. Especially low-bonding and unformed materials.Moisture: LESS than the national standard of 15%. If not, the raw material must be dried.Material size: LESS than 5x5mm, if not; the raw material must be crushed.
Size: 3-5mm;
Moisture content: 10-15%
Final Wood Pellet with Different Size as fuel 6/8/10/12mm1. CE certificate
2. Pellet size: 6mm, 8mm, 10mm (selectable).
3. Pellet length: 20mm-50mm (adjustable)4. Pellet density: 1.1-1.4 g/m3
Application of Wood Pellet :
Complete Wood Pellet Line:
Different Capacity of complete wood pellet production line :
500KG/H; 700-800KG/H; 1000KG/H; 1500KG/H; 2000KG/H;3000KGH;5-10T/H; Also accept customized according customer demand.
Details Introduction for Wood Pellet Production Line :
A--------crushing(crushing these material into 3-5mm powder)B--------drying(if your sawdust has the moisture content more than 25%)C-------pelleting(using our this vertical ring die wood pellet machine with 1000kg/h capacity)D------cooling ans screening(down the pelelts temperature and screning which easy to sote )E------packing(pack the pellets into 25kg/bag, 50kg/bag)

1. Wood Chipper	Processing round wood/logs into wood chips;
2. Crusher	Crushing wood chips into sawdust with 3-5mm
3. Dryer	Drying wet wood sawdust, reduce the moisture ontent to 10-15% from 30-40%
4. Wood Pellet Machine	Making wood sawdust into pellet as fuel, pellet size: 6/8/10/12mm
5. Cooler & Screen	Cooling hot wood pellet, screening the dust out of pellet;
6. Packing Machine	Packaging wood pellets into bags, convenient for transportation/sale an stock.
7. Control Cabinet	Control all machines of wood pellet production line at production site

Packaging & Shipping
Shipment of wood pellet production line/wood pellet machine to customer by 40GP Container
Company Profile
Our Factory and Production Workshop Show:

FAQ: before quote wood pellet machine, pls kindly confirm follows information with us.

(1). What capacity would your prefer? -----The Capacity Range of Wood Pellet Machine: 0.5T/H; 0.8-1T/H; 1.5-2T/H; 2-3T; 3-4T/H.5-10T/H

(2). What is your raw material? -----According to different raw material(such as hard wood, soft wood, straw, rice hust), capacity is different.

(3). What is your raw material size? -----Best size for pressing high quality pellets is 3mm-5mm.

(4). What is the moisture of your raw material? -----Better to be 10-15%. ( If large than this, then we will recommend your Dryer Machine)

(5). Final Pellets Size? -----We have Diameter for Pellets: 6mm, 8mm, 10mm, 12mm. ------Pellets Length: Adjustable20-50mm. (Normally our clients ask pellets length of 33mm, between 30-36mm)

Pls click "SEND" ask for more Catalog & EXW Price of our Wood Pellet Machine Wood Pellet Mill
Recommend Product
300-500KG/H Home Use Wood Pellet Making Line
It consists of the following machines:
1). Hammer Mill;
2). Conveyor
3). Wood Pellet Machine;
4). Coler & Screen;
5). Control Cabinet;
Suitable for processing small wood branch, wood chips, sawdust, straw etc material into wood pellets as fuel for home heating & cooking, for sale and power plant.
800-1000Kg/Hour Biomass Pellet Line

It consists of the following machines:
1). Wood Chipper;
2). Hammer Mill;
3). Conveyor
4). Wood Pellet Machine;
5). Coler & Screen;
6). Packing Machine;
7). Control Cabinet;
Suitable for processing wood/logs; small wood branch, wood chips, sawdust, straw etc material into wood pellets as fuel for home heating & cooking, for sale and power plant.
1000-1500Kg/Hour Wood Pellet Production Line
It consists of the following machines:
1). Wood Chipper;
2). Hammer Mill;
3). Sawdust Dryer;
4). Conveyor
5). Wood Pellet Machine;
6). Coler & Screen;
7). Packing Machine;
8). Control Cabinet;
Suitable for processing wood/logs; small wood branch, wood chips, sawdust, straw etc material into wood pellets as fuel for home heating & cooking, for sale and power plant.
2000-3000Kg/Hour Wood Pellet Production Line
It consists of the following machines:
1). Wood Debarker
2). Wood Chipper;
3). Hammer Mill;
4). Sawdust Dryer;
5). Conveyor
6). Wood Pellet Machine;
7). Coler & Screen;
8). Packing Machine;
9). Control Cabinet;
Suitable for processing wood/logs; small wood branch, wood chips, sawdust, straw etc material into wood pellets as fuel for home heating & cooking, for sale and power plant.
5000Kg/Hour Wood Pellet Production Line
It consists of the following machines:
1). Wood Debarker
2). Wood Chipper;
3). Hammer Mill;
4). Sawdust Dryer;
5). Conveyor
6). Wood Pellet Machine;
7). Coler & Screen;
8). Packing Machine;
9). Control Cabinet;
Suitable for processing wood/logs; small wood branch, wood chips, sawdust, straw etc material into wood pellets as fuel for home heating & cooking, for sale and power plant.
