Birch Wood Pellet Press Machines Rubber Wood Pellet Mill

Product Description

The wood pellets can be made from many different materials,
such as wood and wood related, sawdust, rice husk, sunflower stalk,hulls, forestry wastes ...
Main specficiations of Wood Pellet Mill press machine

Model	Main power	Capacity
XJ560	90KW	1~1.5Ton/hour
XJ700	132KW	2~2.5Ton/hour
XJ850	220KW	3~3.5Ton/hour

More information about Wood Pellet Machine Wood Pellets Machine straw pellet prodution line
(1)Big Gear Box
The gearbox adopts big 3 level drive, with its module increased , gear strengths increased,carrying more and more ability.The service life has been increased 8-10 times than the traditional reducer, so it greatly increase the service life.
(2) Casting material of gearbox with high stability. Gearbox body is casted. Its features strong, good heat dissipation,low heat deformation, high steady etc. In the meanwhile it also avoid disadvantages such as bad sealing for welding boby, easily deformation due to high heat,low steady in basis.
(3) Siemens Brand Motor: This kind of motor is frequency and has thick copper coil, it won't be burned due to instantaneous current.
(4) Parallel vertical installation reduce energy consumption loss. The motor and main shaft of wood pellet machine supplier are parallel vertical installed , which can reduce energy consumption loss in the process of transmission, more output power, higher transformation of energy efficiency.
