Hot Selling Plastic Waste Pet Bottle Recycling Machine Flakes Hot Washing Line
Basic Info.
Model NO.
PET
Material Processed
Plastic Bottle
Plastic Type
PET
Screw
Double-Screw
Automation
Automation
Computerized
Computerized
Certification
ISO9001:2008, CE
Voltage
220V 380V 400V 415V 440V(Customized)
Tank Materials
SUS304
Weight
10-20t
Heating Way
Electric Heating/ Steam Heating
Keywords
Pet Bottle Hot Washing Machine
Bearing
NSK
Washer Type
Cooling Washer+Hot Washer
Contactor
Siemens Contactor
Raw Material
Pet Bottle
Temperature Controller
Rkc/Omron
Color
Customized
Inverter
ABB Brand
Motor Brand
Siemens Beide
Name
Plastic Film Woven Bags Washing Crushing Productio
Transport Package
Wooden Case Covered by Plastic Film
Specification
25mx2.5mx2.2m
Trademark
Camel Machinery
Origin
Zhangjiagang Jiangsu China
HS Code
8477800000
Production Capacity
100PCS/Year
Packaging & Delivery
Package Size
300.00cm * 150.00cm * 200.00cm
Package Gross Weight
6000.000kg
Product Description
Plastic PET Bottle Flake Recycling Washing LineProduct Description
1. This line is mainly used for recycling the waste PET bottle, PET container etc.
2. To separate PET bottles to flakes from label, cap, oil, garbage.
3. This line is composed of separator, crusher, cold & hot washing system, dewatering, drying, packing system, etc.
4. Easy to operate, Full automatic.
5. Production capacity: 300KG/H, 500KG/H, 1000KG/H, 1500KG/H, 2000KG/H
Main Advantage :
1. Automotive line for recycling the PET bottles and other waste plastic profile, except the film.
2. The final product is the cleaning flakes, if you want the final product is pellets, we should equip the granulator line again.
Process flow:
Belt conveyer → Rolling separator →Manual pick table → Metal separator → Belt conveyer → Crusher → Label Separator → Hot washer 1 → Friction washing machine → Hot washer 2 → High-speed friction washing machine → Rinsing tank → Spray washing→ Dewatering machine → Blower dryness system → Storage hopper → Finished product packing Features :
Capacity: 300-2000kg per hour
Moisture of PET Flakes: Less Than 1.5%
Cap &Label separate with the PET bottle flakes automatically
Bottle Types: PET Bottle, Plastic Bucket, Water Bottle, Coke Bottle
Application: PET Strap, PET Yarn Fiber, PET Sheet
| Machine capacity(Kg/h) | 300kg/h | 500kg/h | 800kg/h | 1000kg/h | 1500kg/h | 2000kg/h |
| Balers Opener | / | optional | optional | Yes | Yes | Yes |
| Label Remover | optional | optional | optional | Yes | Yes | Yes |
| Sorting Table | optional | optional | optional | Yes | Yes | Yes |
| Metal Detector | optional | optional | optional | optional | optional | optional |
| Belt Conveyor | Yes | Yes | Yes | Yes | Yes | Yes |
| Crusher | Yes | Yes | Yes | Yes | Yes | Yes |
| Screw Feeder | Yes | Yes | Yes | Yes | Yes | Yes |
| Friction Washer | Yes | Yes | Yes | Yes | Yes | Yes |
| Floating Washer Tank | Yes | Yes | Yes | Yes | Yes | Yes |
| Hot Washer | optional | Yes | Yes | Yes | Yes | Yes |
| Dewatering Machine | Yes | Yes | Yes | Yes | Yes | Yes |
| Air Dryer | Yes | Yes | Yes | Yes | Yes | Yes |
| Silo | Yes | Yes | Yes | Yes | Yes | Yes |
