High Preicsion Spline Shaft for Rolling Mill

Product Description

Product Description
A heavy-duty spline shaft is a special type of mechanical part that is often used in industrial equipment and mechanical transmission systems. Function: Heavy-duty hollow flange shafts are typically used to connect two or more rotating parts such as gears, fan blades or transmissions. It connects rotating parts fixed on the shaft through flanges so that they can rotate together and transmit force and torque. Material selection: Heavy-duty hollow flange shafts are usually manufactured with high-strength alloy steel or stainless steel to ensure that they have sufficient strength and durability. The choice of material depends on the application environment and requirements. Structural design: The heavy-duty hollow flange shaft consists of two main parts: the shaft body and the flange. The shaft body is hollow with a large internal diameter to reduce overall weight and provide room for other transmission components. Flanges are located at both ends of the shaft and are used to connect and fix rotating parts. Manufacturing process: The manufacturing of heavy-duty hollow flange shafts usually involves multiple operations, including turning, milling, cutting, drilling, etc. These operations are used to machine the shaft body and flange and ensure that their size and shape meet the design requirements.

Product name spline Shaft Brand Yogie Process Forging, Machining, Heat Treatment Application large printing machine,airplanes,production machinery, port industry, heavy industry machinery,etc Processing material 45#40CR 20CRM O20CRNIMO 17CRNIMO620CRMNTI42CRMO etc. Module of Gear 8-120 Gear Grinding MAX Module 25 Diameter of Gear Wheel MAX 13 000 mm Diameter of Spiral Gear MAX . 2 200 mm Length of Gear Shaft MAX 5 000 mm Gear Teeth treatment Surface hardening,cemented and quenching Workplant Forging , Casting and Welding

★★★High Load Capacity: Large helical gear shafts are designed to handle significant loads and transmit high levels of torque. The helical gear design allows for a greater tooth engagement, resulting in improved load distribution and higher load-carrying capacity compared to other gear types.

★★★Smooth and Quiet Operation: Helical gears have a gradual engagement of teeth, which reduces noise and vibration during operation. The helix angle of the teeth helps to distribute the load smoothly, minimizing impact and ensuring a quieter gear system.

★★★Increased Efficiency: The helical gear design provides a larger contact area between the teeth, resulting in higher efficiency compared to other gear types. This leads to reduced power losses and improved overall system efficiency.

★★★Greater Tooth Strength: The helical gear teeth are longer and have a larger surface area compared to spur gears, providing increased tooth strength. This makes large helical gear shafts more resistant to wear and fatigue, allowing them to withstand heavy loads and prolonged use.

★★★Improved Gear Meshing: Helical gears offer a gradual engagement of teeth, which results in a smoother meshing action. This helps to minimize backlash, improve gear accuracy, and reduce the likelihood of tooth damage during gear engagement.

★★★Versatility: Large helical gear shafts can be used in a wide range of applications, including industrial machinery, heavy equipment, marine propulsion systems, and power transmission systems. Their versatility makes them suitable for various industries and sectors.

★★★Reliability and Durability: The use of high-quality materials, precise manufacturing techniques, and rigorous quality control ensures that large helical gear shafts are reliable and durable. They are designed to withstand heavy loads, extreme operating conditions, and long service life.
