85-99%C Flake Graphite Expandable Graphite 180- 300ml/G for Fire Retardant EPS Foam /Natural Flake Graphite Powder/Amourphous Graphite/Crystalline Graphite

Product Description

Product Description→Natural Flake Graphite is mainly used for metallurgical, mechanical, electrical, chemical, textile, defense industry, electronics, light industry. Such as refractories, made crucible, Bricks, steel ingot protective agent; for conductive materials, producti on of carbon nanotubes, phone parts, CRT coatings; also can be used as wear and lubrication materials; anti corrosion materials; for casting, foundry, die and high temperature metallurgical materials.
Product Parameters

Type	Spec.	Particle Size	Size(%)		Carbon Contents (%)	Moisture (%)
			Screen Oversize	Screen Undersize
High Carbon Graphite	32Mesh	560 um	≥80		94-99	≤0.5
	50Mesh	300 um
	80Mesh	180 um
	100Mesh	150 um
	150Mesh	100 um	≥75
	-100Mesh	150 um		≥80
	-200Mesh	75 um
Middle Carbon Graphite	32Mesh	560 um	≥80		85-93	≤0.5
	50Mesh	300 um
	80Mesh	180 um
	100Mesh	150 um
	150Mesh	100 um	≥75
	-100Mesh	150 um		≥80

→Expandable Graphite:
Can be expanded graphite sheet expansion characteristics different from other kinds of expansion agent, heated to a certain temperature, due to absorption in interlayer matrix compound decomposition, began to swell, expansible graphite as starting expansion temperature, expansion completely in 1000 °C, the maximum volume. Inflation can reach above 200 times -300 times of the initial volume. After expansion of graphite is called expanded graphite or graphite worms, the original scaly into low density worm-like, formed a very good insulation blanket. Expanded graphite is a carbon source in the inflation system, and thermal barrier, can effective heat insulation, with in the fire heat release rate is low, the quality loss is small, the characteristics of the produced less smoke.
Expanded graphite is a kind of good performance of the adsorbent, especially it has a porous structure, has strong adsorption capacity for organic compounds, expanded graphite can be 1 g 80 g of oil adsorption, thus expanded graphite was designed to all kinds of industrial oil and industrial oil absorbents.
Expanded graphite extremely easy adsorption of oils, organic molecules and hydrophobic substances, used for water environmental treatment has irreplaceable effect to other substances. When it is used for the surface oil removal in granular form, according to the size of the water in oil area and the type of the oil, its dosage is 1 ~ lo % / rn, adsorption time in 15 rain to several hours.
Compared with other sorbents, expanded graphite has many advantages. If use activated carbon for water oil removal, it will sink after adsorption of oil, the adsorption quantity is too small, and not easy to recycle; And some adsorbent, such as cotton, hay, polypropylene fiber, perlite, vermiculite and so on, they are on the oil absorption of the water absorption at the same time, it brings to the post-processing difficult; Expanded graphite on oil adsorption quantity is large, floating in the water after oil absorption, easy to catch recycling, recycling processing is simple, can use extrusion, centrifugal separation, vibration, solvent cleaning, burning and heating extraction method, and no second pollution formed.
Features:
1) strong pressure resistance, flexibility, plasticity and self lubrication;2) of high and low temperature resistance, corrosion resistance, resistance to radiation characteristics;3) Strong seismic characteristics;4) strong conductivity;5) Strong anti-aging properties, resistance to distortion;6) Can resist all kinds of metal melting and infiltration;
7) Widely use for fire retardant EPS foam / Panel
Specification:

Brand No	Volatile (%)>≠	Ash (%)>≠	Moisture (%)>≠	PH Value	Particle Size Screen Oversize	Expansion Multiple
9950300	13	0.7	2.5	3-7	70	300
9950250	13	0.7	2.5	3-7	70	250
9950200	13	0.7	2.5	3-7	70	200
9950150	13	0.7	2.5	3-7	70	150
9950100	13	0.7	2.5	3-7	70	100

Patricel Size	Fixed Carbon (%)	Ash (%)	Volatile (%)	Expansion Ratio (ml/g)	Sulfuric acid content		PH Value	Moisture (%)	Particle Size Screen Oversize
					Before Expansion (%)	After Expansion (%)
EG 32	90-99.9	≤8.0	≤12	200-400	≤2.2	≤1500	3-7	≤1.0	≥80
EG 50				200-350
EG 80				150-250
EG100				100-200

→Micron Natural Graphite Powder
Specification: The particle size ranges from 5μm to 40μm, carbon content 95%-99.9%
Advantages: With a high quality natural flake graphite performance. In the high temperature has a special anti-oxidation, self-lubricating and plasticity, at the same time, has a good electrical conductivity, electric and adhesion.
Use: Micropowder graphite can be used
(1) As a catalyst for the production of chemical fertilizer industry Stripping lubricant
(2) The high temperature lubricant material, corrosion-resistant lubricant material
(3) As mould release anent in power metallurgy or raw material in metal alloy
(4) As packing or catalysts of rubber, plastics and varieties of composite material.
Main property index

Micronized graphite powder Brand No.	Fixed carbon	Ash	Moisture	Particle size
	(%)min	(%)max	(%)min	(um) min
M(-)200mesh	80-99	1.0-20	0.5	75
M(-)325mesh	80-99	1.0-20	0.5	45
M(-)400mesh	80-99	1.0-20	0.5	38
M(-)500mesh	80-99	1.0-20	0.5	30
M(-)600mesh	80-99	1.0-20	0.5	25
M(-)800mesh	80-99	1.0-20	0.5	18
M(-)1000mesh	80-99	1.0-20	0.5	15
M(-)1500mesh	80-99	1.0-20	0.5	10

→Spherical Natural Graphite
Spherical graphite adopts excellent natural scale graphite as material and utilizes advanced process techniques to change the property of the surface and produce products of various fineness in the shape of ellipsoid. It is a new generation of cathode material for the production of lithium ion secondary battery both at home and abroad. It has excellent electrical conductivity, good chemical stability, large capacity for electricity charge and discharge, long service life and environmental friendliness.

YH	Particle size(um)				Tap (g/cm3)	S.SA (m2/g)	Fix Carbon (%)	PH	The interlayer space (nm)	Ferrum (ppm)	Capacity (mAh/g)
	D10	D50	D90	Dmax
YHN6	≥2.0	6.5±1.0	≤14.0	≤20	≥0.6	≤14.0	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN8	≥4.0	8.5±1.0	≤15.0	≤25	≥0.75	≤10.0	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN10	≥5.0	10.5±1.0	≤20.0	≤30	≥0.8	≤9.0	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN12	≥6.0	12.5±1.0	≤22.0	≤35	≥0.88	≤8.0	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN15	≥8.0	15.5±1.0	≤27.0	≤40	≥0.9	≤7.0	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN16	≥9.0	16.0±1.0	≤27.0	≤45	≥0.95	≤6.5	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN17	≥10.0	17.0±1.0	≤28.0	≤50	≥0.95	≤6.5	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN17-T	≥10.5	17.0±0.5	≤27.5	≤50	≥1.0	≤6.5	≥99.95	>5	0.3358±0.0003	≤50	≥360
YHN21	≥12.0	21.5±1.0	≤34.0	≤65	≥1.0	≤6.0	≥99.95	>5	0.3358±0.0003	≤50	≥360

→High carbon Natural Graphite:
Specification: The particle size ranges from 45μm-500μm(325mesh-35mesh), and the carbon content ranges 94 to 99.99%
Advantage: Perfect crystallization, thin flake. Good flexibility, excellent chemical and physical properties, superior conductivity, self- lubricity and resistance to temperature, corrosion, hot shock and more.
Usage: Crystalline flake graphite is widely used as an essential nonmetallic mineral in almost all industries. It can be used as high quality refractory material or coatings in metallurgical industry, black lead in fertilizer industry, carbon brush in electronics., electrode in battery industry and catalyst in chemical fertilizer industry, After being deep processed, crystalline flake graphite can be used to produce TV tube coatings, graphite friction reducing additives and other high-tech products.
Features
1. Perfect crystallization
2. Thin flake, good flexibility
3. Excellent chemical and physical properties
4. Superior conductivity
5. Self-Inbrictity and resistance to temperature,
6. Corrosion and hot shock
Production
Usage:
Crystalline flake graphite is widely used as an essential nonmetallic mineral in almost all industries, it can be use as high-quality refractory material or coating in metallurgical industry, stabilizer inmilitary industry, black lead in light industry, carbon brushin electronics industry , electrode in battery industry and catalyst in chemical fertilizer in industry, to name just a few. After being deep processed, crystalline flake graphite can be used to product TV tube coating graphite sealing material and composite meteral. graphite products, graphite friction reducing additives and many other high-techproducts
Application
