Multiple Function Heat Transfer A4 Thermal Label Printer

Product Description

Multiple Function Heat Transfer A4 Thermal Label PrinterDescription Thermal printer, the use of thermal printing technology, that is, the use of special thermal paper, under high temperature chemical reaction and discoloration, in order to achieve the printing effect. Compared with needle printing, thermal printing technology has many characteristics such as low noise, fast speed and clear printing, and has been widely used in banking systems, POS terminal systems, medical devices and other aspects.

Thermal printer principle - comparison
Advantages	low noise, fast speed, clear printing, easy to use
Disadvantages	can not be double printing, printing paper can not be permanently stored
Applicable	Suitable for printing documents that do not need to be kept for a long time.

Needle printer - comparison
Advantages	double printing, printing paper can be permanently stored;
Disadvantages	loud noise, slow speed, unclear printing, inconvenient us
Applicable	It is suitable for printing invoices and other documents that need to be stored for a long time.

Technical Parameters

Project	X216-ii
Printing method	Line thermal printing
Printing width	216mm(2560dots)
Paper width	MAX216mm
Paper thickness	60~100g/m²
Paper diameter	Outer diameter:Max150mmInner diameter:Min25.4mm
Print resolution	300dpi
Dot density	11.8dots/mm
Paper Feed method	180°auto feed
Print speed	MAX120mm/s
Paper out mode	Flick ticket mode, clip ticket mode
Character set	FONT A:12×24(1.02×2.03mm)dot character FONT B:9×17(0.76×1.44mm)dot character Chinese character:Support for GB18030 Simplified Chinese (downward compatible with GB2312-1980) Note: GB18030 currently supports only double-byte zones 1, 2, 3, 4, and 5
Barcode	1D code:EAN8,EAN13,CODE93,CODE1282D code:QR,PDF417
Interface	RS232/USB
Receive buffer	2MB
Instruction set	ESC/POS
Cutter	Auto cutter,full-cut
Power	24VDC±10%,6A
Energy consumption	150W
Operating Environment	Temperature:0~50ºCHumidity:20~85%RH(No condensation)
Storage Environment	Temperature:-25~70ºCHumidity:0~90%RH(No printing paper, no condensation)
Reliability	Print Life:100KMCutter life:300000 cuts

Production FeatureSmall size,easy integration into terminal equipment
Supports 210mm wide printer paper
Support real-time control of print quality
Supports automatic paper feeding mode
Support USB/RS232 communication modes
Supports GDI print mode
The function of black calibration bit ensures the consistency of bill length
With the function of paper will be full detection, early warning paper surplus
Support out of the paper detection function, the realization of ticket clip mode and bounce mode Product
Application:
Banking, communications, medical, public safety, transportation, social insurance, energy,oil station, water and electricity, government affairs, education.
