Double Mast Hydraulic Aluminum Vertical Man Lift, Telescopic Man Lift
| US$1,000.00-3,650.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
GTWYSERIES-200
Carrying Capacity
Middle-Level
Moves
Stationary
Driven Type
DC or AC, DC and AC
Running Mode
Moving
Feature
Explosion-Proof, Insulating, Limit Switch
Certification
CE, ISO 9001
Delivery
15 Days or Rush as Requested
Warranty
12 Months Apart From Man-Made Faults
Safe Working Load (Kg)
200-300
Max Platform Heigght (M)
6-14
Max Working Height (M)
7.7-15.7
Platform Size (M)
1.18*0.62-1.48*0.62
AC (VAC/Kw)
220/1.1
DC (Option)(VDC/Kw)
24/0.8
Accumulator (V/Ah)
2*12/80, 2*12/100
Charger (V/a)
24/10
Transport Package
Steel Pallet+Buffer Sponge+Bubble Bag+Water Proof4
Specification
380-760 KG
Trademark
BOONAI
Origin
Xiangcheng District, Suzhou, China
HS Code
8428909090
Production Capacity
200 Units Per Month
Product Description
Application:1-2passengersMax height of platform :6m,8m,9m,10m,12m 14m
Features:two passengers allowable ,small footprint ,less weight ,easily moved,able to access to limited passageway,the most ideal equipment for aerial work to replace ladder or rigger ,with high efficiency and more security
Standard Configuration
Power supply:single phase AC(AC220V)
Move mode:manual(default)
Driving unit :one unit hydraulic pump,small volume and less noise.
others:
1,Hand shank enables easy steering
2,Leveling of platform is guaranteed by adjusting outriggers with screws
3,Electric limit switch shall cut off power when up limit is reached
4,Ground/platform control modes are available,rendering possibility of one operator
5,Stroke protection block is build in hydraulic cylinder for security
6,Emergency lowering system is equipped
7,Raise-and-fall guard rail,rendering minimum height of equipment when in storage status,easy to install
8,Leveling indictor is equipped
| Model | GTWY6-200 | GTWY8-200 | GTWY9-200 | GTWY10-200 | GTWY12-200A | GTWY12-200B |
| Safe working load(kg) | 300 | 200 | 200 | 200 | 200 | 200 |
| Number of passengers | 2 | 2 | 2 | 2 | 2 | 2 |
| Max height of platform(m) | 6 | 8 | 9 | 10 | 12 | 12 |
| Max working height(m) | 7.7 | 9.7 | 10.7 | 11.7 | 13.7 | 13.7 |
| Overall length (m) | 1.38 | 1.38 | 1.58 | 1.58 | 1.62 | 1.68 |
| Overall width(m) | 0.85 | 0.85 | 0.95 | 0.95 | 0.95 | 0.95 |
| Overall height (m) | 1.85*1.78 | 1.85*1.78 | 2.15*2.00 | 2.15*1.90 | 2.21*2.04 | 2.30*2.09 |
| Extended outrigger (lxw)(m) | 1.85*0.62 | 1.18*0.62 | 1.38*0.62 | 1.38*0.62 | 1.38*0.62 | 1.48*0.62 |
| Size of platform(m) | 1.18*0.62 | 1.18*0.62 | 1.38*0.62 | 1.38*0.62 | 1.38*0.62 | 1.48*0.62 |
| Lifting motor | ||||||
| AC(VAC/kw) | 220/1.1 | 220/1.1 | 220/1.1 | 220/1.1 | 220/1.1 | 220/1.1 |
| DC(option)(VDC/kw) | 24/0.8 | 24/0.8 | 24/0.8 | 24/0.8 | 24/0.8 | 24/0.8 |
| Accumulator(V/AH) | 2*12/80 | 2*12/80 | 2*12/100 | 2*12/100 | 2*12/100 | 2*12/100 |
| Charger(V/A) | 24/10 | 24/10 | 24/10 | 24/10 | 24/10 | 24/10 |
| Wheel | ||||||
| Front wheel (in) | 6 | 6 | 6 | 6 | 6 | 6 |
| Rear wheel (in) | 6 | 6 | 6 | 6 | 6 | 6 |
| Overall weight(kg) | 380(AC) | 480(AC) | 548(AC) | 610(AC) | 650(AC) | 650(AC) |
| 425(DC) | 525(DC) | 593(DC) | 665(DC) | 700(DC) | 700(DC) |
| Optional Configuration |
| Power supply: Battery Dc with charger ,suitable for outdoor operation |
| Move mode: 1,Electric moving device is equipped in case of long distance travel |
| 2,Could be built in carriage of truck |
| 3,Trailer base could be provided in case of outdoor operation |
| Others: |
| 1,Extendable platform (not for B type) |
| 2,Insulated platform |
| 3,Explosion-proof electrical system |
| 4,Overload alarm |
| 5,Outrigger limit switch |
| 6,Tilt alarm |
| 7,AC power to platform |
| 8,Working alarm |
| 9,Rubber dust stop |
| 10,Explosion-proof valve for oil tube |
Ray
Boonai(Suzhou)Lift Equipment Co.Ltd
Cell phone:18762898105
Tel:0512 65382883 Fax:0512 65382264
