74 Power Head CNC Drilling Multi Axis Pneumatic Head

Product Description

Product Description
Characteristic 1. Experience unparalleled precision with our Pneumatic Drilling and Tapping Machine, featuring the B16 Spindle Taper. This machine can be seamlessly integrated with multi-axis configurations of two or four axes, enhancing your drilling capabilities with impeccable accuracy.
2. Enjoy remarkable energy savings and outstanding efficiency, making it an ideal choice for modern industrial applications.

The main technical parameters
Speciflation	SS-74 automatic drilling machine	SS-92 automatic drilling machine
Spindle Taper	B16	B16
Buffer travel	30mm-60mm	30mm-60mm
spindle travel	80mm	80mm
spindle speed	1400-4000	1400-4000
Max drilling capacity	1.5mm-8mm	2mm-16mm
motor power	0.75kw	0.75kw
Number of available multiple shafts	2-4	2-10

Hot Product
Company Information

FAQ
1. Can the drilling machine do tapping work?
No, the drilling machine is specifically designed to drill holes.
2. Is the spacing of the machine adjustable?
Yes, it offers adjustable spacing to accommodate diverse usage requirements, ensuring versatility in operation.
3. Is the cutting tool easy to break?
Operate it normally, and you'll find it resistant to breakage, ensuring durability and reliability.
4: If we need a non-standard machine, what should we provide?
To customize a non-standard machine, please provide us with the following essential details:
1: A comprehensive drawing of your product.
2: Samples of your product for precise customization.
3: Specifications including the product's height, width, and thickness.
4: The maximum and minimum range of the holes required.
5: Material specifics like thickness, width, and the number of drilling and tapping holes needed for your products.
5: Can the non-standard machines perform both tapping and drilling?
YES, they are fully capable of executing both functions.
6. Payment term
After signing the contract, initiate with a 40% deposit to activate the agreement.
7. Arrange production
Upon deposit receipt, mass production commences promptly. Expect completion for CNC milling machines within 20 days, and automatic drilling and tapping machines within 15 days.
8. Package
We advise choosing wooden box packing to safeguard your products against potential damage during transit.
9. Check the acceptance Upon receiving the goods, conduct a thorough inspection for any packing damage, leakage, or product damage. Verify that the product quantity and accessories match your order. If machine details are unsatisfactory, promptly capture images and reach out to us.
10. Warranty time
Enjoy a one-year warranty. For the first year, parts are provided free of charge unless damage is intentional. We offer lifetime maintenance. Post-warranty, component and shipping costs apply.
We offer on-site debugging and customer training; however, customers bear the cost. This includes airfare between China and the destination, along with complimentary accommodation and meals.
The 12-month warranty starts the day your machine arrives. If issues arise, our engineers will be on-site within 24 hours post-notification. Our support continues even after warranty expiration. Every CNC machine ships with comprehensive English maintenance and operation manuals.
11. OEM Service
We welcome purchase orders featuring customers' brands or trademarks, accommodating personalized business needs.
