AS-E504-UVIR3 Explosion-Proof Ultraviolet and Infrared Combined Flame Detector

Product Description

Product Description
AS-E504-UVIR3 Explosion-Proof Ultraviolet and Infrared Combined Flame Detector

☆ AS-E504-UVIR3 flame detector provide a new generation of flame detector that is highly performance improvements and technical innovations.
☆ AS-E504-UVIR3 flame detector adopts a patented signal processing algorithm, which can suppress various radiations brought by the sun, artificial lighting, welding, lightning strikes and "black body". It can provide continuous protection in the environments where infrared radiation and frequent false alarm sources are present.
☆ AS-E504-UVIR3 flame detector has a feature of sensor automatic optical inspection calibration. It's suitable for indoor and outdoor applications where a suppression of false alarms and excellent fire detection performance are required.
Product Features ☆ Four bands: UV 185~260nm; IR 3.8um / 4.3um /5.0um.
☆ High sensitivity can provide fast alarm, response time≤5s.
☆ The detection distance of n-heptane can reach 180 feet (55 meters).
☆ With lens pollution self-check function.
☆ Standard two-way relay output: fire alarm and fault.
☆ Independent high-precision 0 to 20mA current loop output.
☆ Support RS-232 digital communication protocol.
☆ The detector is made of stainless steel, can use in extremely harsh environments.
☆ Excellent combination of flame detection performance and false alarm suppression.
☆ Automatic optical integrity detection of lens controlled by microprocessor.
☆ Good universality for application scenarios.
☆ Low coverage cost and maintenance cost.
☆ Smaller fires can be detected as early as possible.
☆ Good ability to detect and partition.
☆ Reliable fault diagnosis and pollution monitoring.
☆ Strong anti-electromagnetic interference capability.
☆ Sensor automatic optical inspection calibration.
☆ High flexibility and wide compatibility.
Detailed Photos
Parameters:

Model No.	AS-E504-UVIR3
Power supply	24VDC
Standby Current	≤30mA
Alarm Current	≤50mA
Angle Range	120°
Spectral Range	IR 3.8~5.0uM, UV185~260nm
Sensor Type	Ultraviolet and Infrared
Housing Material	Stainless steel
Explosion Proof Mark	EXd II C T6 Gb
Operating Temperature	-10°C~55°C
Operating Humidity	0~95%RH

Detection Specifications:
Installation Methods: Wiring Terminals:
Applications:
