Supply High Quality Titanium Plate ASTM B265 Gr2
| US$15.00-50.00 | 1 KG (MOQ) |
Basic Info.
Model NO.
Gr1, Gr2, Gr3, Gr5, Gr7, Gr9, Gr12
Technique
Hot Rolled,Cold Rolled.
Grade
Gr1 ,Gr2,G,Gr7,Gr9,Gr12
Shape
Square
Width
3mm-1500mm
Thickness
0.4-500mm
Length
3mm-2500mm
Type 1
Titanium Bars Titanium Sheets Pipes Wire Foil
Application 1
Industrial Medical
Technique 1
Forged Hot Rolled Seamless Cold Rolled
Transport Package
Standard Export Package.
Specification
as customers′requirement.
Trademark
Tianjin Yitejia Steel
Origin
Tianjin China
HS Code
81089040
Production Capacity
100 Tons/Month
Product Description
COMPANY PROFILE1.SGS and BV Audited company.
2.Industry experience over 10 years.
3.Management Systems-Internal Software
4.Finished Product Inventory-More Than 500 Tons.
5.Raw Material inventory -Over 800 Mertic Tons.
6.Shipment of goods -More than 30 countries worldwide.
7.We have the most convenient transport and prompt delivery.
8.We offer competitive price with best service.
9.We have high technical production line with top quality products.
10.We have win high reputation based on best quality products.
PRODUCT DESCRIPTION
| Company | Tianjin Yitejia Steel Sales Co.,Ltd. |
| Description | Titanium plate, Titanium sheet, Titanium coil |
| Material | Gr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25 TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4 |
| Standard | ASTM B265,ASME SB265,DIN17851,TiA16Zr5Mo1.5,JIS4100-2007,GB3461-2007 |
| Size | Cold rolled: Thick 0.02mm ~ 5mm * Wide 1500mm max * Long 2500mm max Hot rolled: Thick 5mm ~ 100mm * Wide 3000mm max * Long 6000mm max |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc |
| Payment term | TT,L/C |
| MOQ | 100Kg |
| Export to | Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil,Thailand,Korea, Iran,India,Egypt,Oman,Dubai,Kuwait,Peru,South Africa,Russia,Malaysia,Chile,etc |
| Package | Standard export package,suit for all kinds of transport ,or as required. |
| Container Size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High) |
| Application | 1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm². 2.Titanium and titanium alloy in aviation industry, is called "space metal"; In addition, in the shipbuilding industry, chemical industry, manufacturing machinery parts, telecommunications equipment, hard alloy, etc have increasingly extensive application 3.In addition, because of the titanium alloy with the human body has very good compatibility, so the titanium alloy can also be artificial bone. |
| Contact | If you have any question ,please feel free to contact me . We are sure your inquiry or requirements will get prompt attention. |
CHEMICAL COMPOSITION
| Grade | N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | Bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | Bal |
| Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | Bal |
| Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5-6.75 | 3.5-4.5 | / | / | / | Bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12-0.25 | / | / | Bal |
| Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5-3.5 | 2.0-3.0 | / | / | / | Bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 02-0.4 | 0.6-0.9 | Bal |
MECHANICAL PROPERTIES REQUIREMENTS
| Grade | Tensile strengt(min) | Yield strength(min) | Elongaion(%) | ||
| Ksi | MPa | Ksi | Mpa | ||
| Gr1 | 35 | 240 | 20 | 138 | 24 |
| Gr2 | 50 | 345 | 40 | 275 | 20 |
| Gr3 | 65 | 450 | 55 | 380 | 18 |
| Gr4 | 80 | 550 | 70 | 483 | 15 |
| Gr5 | 130 | 895 | 120 | 828 | 10 |
| Gr7 | 50 | 345 | 40 | 275 | 20 |
| Gr9 | 90 | 620 | 70 | 438 | 15 |
| Gr12 | 70 | 438 | 50 | 345 | 18 |
