Spray Drying Detergent Powder Plant Ideal for Large Scale Production with High Efficiency

Product Description

Product Description
Technology characteristics
a.The waste gas of whole production system reaches the emission standard, no sewage discharge.
b.After drying, Tail-gas is dealt by primary cyclone dust removal and secondary water dust removal. Save energy and reduce consumption, emissions reach the normal standard.
c.Fine powder collecting from dedusting process is completely back to tower, water can be recycled, and the precipitated slurry after collecting can be used for proportioning.
d.Workshop environment is provided with perfect dedusting system, ensure the workshop environment clean.
e.Factory and workshop have reasonable logistics, rational configuration, save the operating expense.
f.Control system can adopt simple manual operation or central computer integrated automatic control.
g.Good uniformity in powder particles and components, excellent solubleness and stable quality.
Detergent Powder Production Line
We provide process design, equipment manufacturing, installation, commissioning and operation training for the washing powder production line of 5,000 to 250,000 tons/year.Process configurations from simple manual operations to centralized automation of central computers can be designed. We also undertake technical consulting and old line engineering services. Our company has successfully provided technology and services to approximately 160 washing powder plants worldwide. Including Unilever, P & G, Indonesia Wings, Myanmar Rose Detergent Factory, Yemen Red Sea, Nice Group, Liby Group, Topseller Chemical, Guangdong Lonkey, etc. Adopt the process of high spray tower. Apparent specific gravity of product is 0.25~0.50g/cm3.All kinds of powder materials, liquid materials are weighed respectively according to the formula, , sent to slurry preparator to make slurry, after hydrated aging, crushing and filtering by aging system, sent to the top of spray tower by high pressure pump. Form mist particles through spray nozzles, dried by hot air generated by hot air furnace. At the bottom of the tower, hollow particles of detergent powder are formed. Then by air lifting, aging, base powder is made. After sieving, other materials (such as enzyme, color particles, essence, non-ionic, etc.) shall be added into base powder, and then put together into the post-blending mixer. After mixing and granulating, final detergent power in medium & top grade is made, and eventually packing. Detergent Powder Production Machine of Low investment 1. The exhaust gas is discharged to the standard and there is no sewage discharge.
2. Save energy and reduce consumption, and discharge to normal standards.
3. The fine powder collected from the dust removal process is returned to the tower, the water can be recycled, and the collected sediment slurry can be used for the ratio.
4. Establish a complete workshop dust removal system, clean the operating environment
5. The factory and workshop have reasonable logistics and reasonable configuration, which saves operating expenses.
6. The process design is advanced and the plan is reasonable.
Name Application Usage Function Capacity Function Advantage

Stainless Steel Washing Powder Production Line

Daily chemical

Produce washing powder

Screw conveyor

>1 ton/hour

Mixer blender

High efficiency;Environment-friendly

Name	Post Blending Detergent Powder Production Line
Application	Daily chemical
Usage	Produce washing powder
Main Material	Base Powder
Capacity	>1 ton/hour
Function	Mixer blender
Advantage	High efficiency; Environment-friendly; Low investment

Name	Concentrated Powder Production Line
Application	Daily chemical
Usage	Produce concentrated powder
Main materials	Surfactant, soda ash, silicate, perfume, etc
Capacity	>= 1 ton/year
Function	Mixer
Advantage	high density, low foam, low investment and operation cost

Name	Spray Tower Detergent Powder Production Line with Turnkey Project
Application	Daily chemical
Usage	Produce washing powder
Function	Screw conveyor
Capacity	>1 Ton/hour
Function	Mixer blender
Advantage	High efficiency; Environment-friendly

Application
Packaging & Shipping
Related Products
Customer Review
Company Profile
Zhejiang Meibao Industrial Technology Co., Ltd
Zhejiang Meibao Industrial Technology Co., Ltd is a technology professional company specializing in factory planing, process design, equipment manufacturing, installation, commissioning service and training for the complete sets of daily chemical production line, energy equipment and so on. There are almost 200 professionals in R&D, design, manufacturing, installation and after-sales in our company. We have the modern manufacturing factory. We can provide planning, design, manufacturing, installation, commissioning and training of complete production line, detergent powder output capacity at 5000~250000 tons/year and liquid detergent output capacity at 5000~250000 tons/year. We also provide technical consultation and reconstruction services of old lines and have successfully designed and supported such production line as detergent powder, liquid detergent, wet sodium silicate and solid sodium silicate for many companies at home and abroad. At the same time, our company also can provide a variety of product formulations and raw materials that adapt to the market according to user needs. For the energy equipment, we mainly designs and manufactures a variety of special industrial furnaces, including direct hot air furnace, indirect hot air furnace, biomass fired hot air furnace, oil gas hot air furnace, regenerative exhaust gas furnace and so on. Our products have been used in the production lines of many well-known manufacturers such as Unilever, Indonesia P.T.Wings Surya, Indonesia PT. Pacinesia Chemical Industry, Ittehad Chemicals Ltd(Pakistan), Singapore International Rubber Industry Co., LTD, US P&G, Germany Henkel, NICE Group, Guangzhou Liby Group and so on, and exported to Vietnam, India, Laos, Myanmar, Indonesia, Pakistan, Thailand, Tanzania, Ghana, Jamaica, Zambia, Dominica, Angola and other countries. Adhering to the business philosophy of "people-oriented, scientific and technological innovation, respect for nature, rational utilization and sustainable development, benefit the society", we always provide customers at home and abroad advanced technology, first-class products and perfect service. We insist on that when we give customer the benefit and assurance, we also contribute to the continuous development of energy in china and improvement of people's life. Exhibition
Certifications
1. Who are we?
We are Zhejiang Meibao Industrial Technology Co., Ltd, based in Zhejiang, China. We are a technology professional company specializing in factory planning, process design, equipment manufacturing, installation, commissioning service, and training for complete daily chemical production lines and energy equipment. Our team comprises nearly 200 professionals in R&D, design, manufacturing, installation, and after-sales services.
2. How can we guarantee quality?
We ensure quality through:
A pre-production sample before mass production
Final inspection before shipment
3. What can you buy from us?
You can purchase:
Detergent Powder Plants
Chemical Complete Plants
Daily Chemical Machinery and Equipment
Inorganic Chemical Complete Plants
Chemical Raw Materials
4. Why should you buy from us and not from other suppliers?
We are committed to excellence in household chemicals, basic chemicals, petroleum, and natural gas. Our core competencies include advanced technology development, design capabilities, international engineering management, and exceptional customer service.
5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF
Accepted Payment Currency: USD, EUR
Accepted Payment Types: T/T, L/C
Languages Spoken: English, Chinese
6. What industries do we specialize in?
We specialize in daily chemical production lines, energy equipment, and related technologies, including factory planning, process design, and equipment manufacturing.
7. What is our production capacity for detergents?
We can handle detergent powder output capacities ranging from 5,000 to 250,000 tons/year and liquid detergent capacities in the same range.
8. What types of energy equipment do we design and manufacture?
We design and manufacture various industrial furnaces, including direct and indirect hot air furnaces, biomass-fired furnaces, and regenerative exhaust gas furnaces.
9. Can we assist with existing production lines?
Yes, we offer technical consultation and reconstruction services for upgrading and improving old production lines.
10. What are our key markets?
Our products are used by major manufacturers globally and are exported to countries like Vietnam, India, Indonesia, and many more.
11. What is our approach to innovation and sustainability?
We focus on technological innovation, rational resource use, and sustainable development to benefit society and improve lives.
12. What type of product formulations do we offer?
We provide a variety of product formulations and raw materials tailored to market needs and customer specifications.
