Negotiable |
50 Pieces
(MOQ)
|
Basic Info.
Internal Structure
On-Off Type
Power Source
Half-Bridge Type
Production Capacity
6000000/Year
Product Description
Universal Laptop Adapter Charger 60W 19V 3.16A Connector 6.5*4.4mm for HP laptop
Rang of application | LAPTOP CHARGER / ADAPTER |
Input specification | Input voltage | 100-240V ( worldwide use) |
Input frequency | 50-60Hz |
Output specification | Output voltage | 19V |
Output current | 3.16A |
Output power | 60W |
Voltage regulation | ±0.3V |
Protection function | Overload protection | Beyond the rated power 5%-10%, automatic recovery |
Over-voltage protection | 10%-13%Out of rated voltage |
Short Circuit | No damage for short circuit,automatic recovery |
Environmental | Operating temperature | 35°C-55°C |
Storage temperature | -20 °C-85°C |
Humidity | 5%-25% No condensation of moisture |
AC specification | Three plug 3PIN | Device type | plug in adapter |
structure | weight | 250g | Ripple | <=230MV |
Size | 109*47*31mm | Safety standards | CE FCC |
External dimension | 6.5mm | Service | OEM ODM |
Internal dimension | 4.4mm | Warranty | 1 year warranty |
