Auto Granite Slab Polishing Line Stone Grinding Machine
| US$39,500.00-53,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
GBLXM-1200
Precision
High Precision
Application
Granite
Type for Grinding Machine
Disc Grinding Machine
Grinding Machine Type
Vibration Polishing Machine
Grinding Method
Wet Grind
Certification
ISO, CE
Condition
New
function
grinding granite slab
Operation
Auto and easy
main motor
7.5kw for each head
Key word
granite slab grinding machine
color
customer needing
control system
PLC auto system
Transport Package
Water-Proof Plastic Film Package
Specification
10800*2210*2200mm
Trademark
Great Base
Origin
Fujian, China
HS Code
84642090
Production Capacity
500sets/Year
Product Description
GBLXM-1200 Auto Granite Slab Polishing LineFeatures:
It adopts PLC terminal control system; Operator can set the parameters by the programmable controller with LCD screen. It is equipped with trouble alarm and abrasive block consumption alarm systems. It is qualified for continuous grinding and polishing granite stone slabs. The speeds of work piece conveyor and cross beam adopt converters to adjust their speed. Its processing width and working pressure of grinding heads are adjustable. Each grinding head can rise and fall automatically following the work piece movement. The machine also has the function of avoidance. Meanwhile, the main motor of this machine is only 7.5kw with 16 pcs and it uses the common round abrasive, so that it has the high efficiency energy saving and environmental protection function.
We have sold this kind of machine to some factories in China. After long-time inquiry, we have got the probable efficiency data.
Technical data:
| Name | Unit | GBLXM-1200-12 | GBLXM-1600-16 | GBLXM-2000-20 |
| Max. polishing width | mm | 600-1250 | 600-1600 | 600-2000 |
| Useful working thickness | Mm | 13-50mm | ||
| Useful abrasive | D.200mm resin abrasive disc | |||
| Speed of conveyer belt | Mm | 0-2800mm | ||
| Frequency of front-back swing | Times/min | 30 times/m( go and back) | ||
| Main power | KW | 7.5kw*12 | 7.5kw*16 | 7.5kw*20 |
