1200*2400mm Gypsum Board Plasterboard Interior Panel with Drywall Waterproof Sheets

Product Description

A : We have many types of gypsum board as below :
1). Standard gypsum board (white color )
2). Fireproof gypsum board (Pink color )
3). Moistureproof gypsum board (Green color )
4). Waterproof gypsum board ( Green color )
5). Soundproof gypsum board ( Purple color )
6). Perforrated gypsum board and PVC laminated gypsum ceiling
B: Edge : square or Tegular
Glass fiber makes gypsum board stronger
The Less the paper gooten, the better joint between paper and gypsum
Detailed Photos
Product ParametersThe following are the parameters of our products.

Product Name	Paper faced gypsum board
Material	Paper +Gypsum powder+fiberglass +Others
Type	Standard / Fire-proof /Moisture-proof /Water-proof /Sound-proof
Paper color	White/Brown/Pink/Green/Blue
Feature	Sound Absorption , Fire-proof ,Waterproof ,Heat insulation, Easy to install,Dimensionally stable , Long life,Environmentally friendly ,light weight ,No sag No warp .
SIZE MM	1200*2400/1200*2600/1200*2700/1200*3000/1220*1830/1220*2440 or others
THICKNESS	7/8/9/9.5/10/12/12.5/15MM
Edge	Tegular edge /Square edge
Packing	Every two pieces face to face packed with sealing paper
Shipping mark	the sealing paper could be printed accoridng to customer demand but have qantity demand

PACKING SPECIFICATION
SIZE MM	THICKNESS MM	WEIGHT /PC KGS	20'FCL (LOAD IN BULK )			40'HQ(PALLET PACKING )
			PCS	SQM	KGS	PALLET QTY	PCS	SQM	N.W.KGS	G.W.KGS
1200*2400	9	16.8	1000	2880	16800	15	1570	4522	26376	28876
	9.5	17.2	950	2736	16340		1530	4406	26316	28816
	10	17.5	890	2563	15575		1500	4320	26250	28750
	12	21.2	740	2131	15688		1240	3571	26288	28788
	12.5	22.8	710	2045	16188		1150	3312	26220	28720
	15	24.6	590	1699	14514		1070	3082	26322	28822
1220*2440	9	17	970	2887	16490	15	1520	4525	25840	28340
	9.5	17.6	920	2739	16192		1480	4406	26048	28548
	10	18	860	2560	15480		1450	4316	26100	28600
	12	21.6	716	2131	15466		1200	3572	25920	28420
	12.5	23.2	686	2042	15915		1110	3304	25752	28252
Application	Interior ceiling or wall partition and residential places such as restaurant , hotel ,supermarket ,kitchen ,living room and so on
Loading date	Around 7-15 days after deposit payment
Produce capacity	500000sqm/Day
Port of Loading	Qingdao Or Lianyungang
Sample	Small size free sample can be supplied , and customer bear the transport charge

Step 1: Construct a pair of T-braces from 2 X 4s about an inch longer than the distance from floor to ceiling. Nail 2 X 4s about 3 feet long to one end of each longer 2 X 4 to form the Ts. Alternately, adjustable T-braces can be rented.
Step 2: Cut drywall panels to size. Use a sharp utility knife along a straightedge to cut drywall. After you make the cut through the face paper, place the board over a length of 2 X 4 laid flat on the floor, or some other type of support, and snap the scored section down. The gypsum core will break along the line you cut. Then turn the panel over, cut the paper on the other side, and smooth the rough edges with very coarse sandpaper on a sanding block.
Step 3: Install drywall panels on the ceiling. If possible, try to span the entire width with a single sheet of wallboard to reduce the number of joints. Position and wedge the T-braces against the drywall sheet to hold it in place until you finish nailing it.
Step 4: Drive nails at 6-inch intervals into all the joists covered by the sheet. Start in the center of the drywall panel and work out. Give each nail an extra hammer blow to dimple the surface slightly without breaking the face paper.
Step 5: When the ceiling is finished, cut and install wall panels. Carefully measure for any cutouts in the drywall, including electrical outlets, switches, or light fixtures. To make cutouts, draw a pattern of the cutout on the wallboard, drill a hole on the pattern line, and then use a keyhole saw to follow the pattern.
Step 6: Space the nails 6 inches apart along studs, but start nailing 4 inches from the ceiling. Butt the wall panels against the ceiling sheets. Dimple all nails. Nail metal outside cornerbeads to cover any outside corners.
Our AdvantagesThe use of gypsum board
Our gypsum boards can be used for partitions and ceilings. Fireproof gypsum boards aresuitable for kitchens or fireplaces, waterproof gypsum boards are suitable for bathrooms ortoilets; moisture-proof gypsum boards are suitable for damp cellars; perforated gypsum boardscan absorb a certain amount of noise and are suitable for soundproofing. Qur products can beused in a variety of places to meet all your choices.
Packaging & Shipping
Related Products
The Accessories could be supplied :
1) Galvanized channel like track channel and stud channel for wall partition.
2) Galvanized channel like main channel and furring channel for ceiling.
3) Joint compound ,putty powder, gypsum powder.
4) glass wool ,rockwool.
5) joint tape .mesh tape , paper tape , metal tape.
6) metal nails .nut etc.
7) PVC laminated gypsum ceiling and t grid.Certifications
Teams and partners
FAQ
Q1: Can l have a sample?
A: Yes, please contact us. We will provide it to you upon request.
Q2: What is the average production time? How can l get the products in time?
A: Our average production time is around 7-15 days within 100000 square meters. We have more than 140 modem product lines to ensure your delivery time.
Q3: What can l buy from you?
A: Gypsum board and Galvanized Channel , Gypsum ceiling and T grid and other accessories . WPC wall panel, PVC marble sheet , wood veneer, AKU board, fiberglass panel, etc
Q4: How can l know the shipping cost and custom tax rate?
A: We could check with the shipping company and let you know, the customer clearance service also could be offered if you need .
Q5: Can the packaging and logo be customized?
A: The packing and logo can be customized according to customer requirements, but it needs to reach a certain quantity. We can also provide logo design services .
Q6: About the quality ?
A:We have a strict quality managements system , we will ensure that there are no quality issues with the product and resolve all potential hazards before loading .
Q7:About after-sale ?
A:We promise to follow up and help customs solve after-sales problems and never shirk responsibility .
Q8:About infringement ?
A: We confirm that all of our products do not involve any infringement issues .
