| Model | VR-6525S |
| Configuration | Desktop |
| Operation mode | Big LCD control panel,Double-roll feeder |
| Mastering mode | High speed digital thermal plate master-making |
| Scan mode | Book scan |
| Printing mode | Fully automatic stencil printing |
| Original type | Sheet/Two-in-one/ Book (≤10kg) |
| Image Processing Mode | Text/Picture/Text&picture/Newspaper/Pencil/ Screen |
| Master-making speed | 19s |
| Resolution | 300*600dpi |
| Original size(min/max) | 310*432mm(max) |
| Scan area(max) | 297*420mm(A3) |
| Printing area(max) | 252*358 mm |
| Paper size(min/max) | 90*140mm(min)~310*432mm(max) |
| Paper weight(min/max) | 40~128g/m2 |
| Paper feeding capacity | 1000 sheets(70g/m2) |
| Paper receiving capacity | 1500 sheets(70g/m2) |
| Print reproduction Ratio | Reduction: 71%,81%,87%,94%; Enlargement :100%,115%,122%,141%. Free zoom:50~200%(1% increment) |
| Print speed | Five Steps Variable (55,70,85,105,130 ppm) |
| Scan density | 5 variable ( lighter,lighter, middle, dark, darker) |
| Master density | 5 variable ( lighter,lighter, middle, dark, darker) |
Image position/ Print Position Adjustment | Horizental:±10mm,Vertical±10mm |
| Master eject capacity | 50 sheets |
| Optional parts | Pager, Color drum |
| Standard Features | On-line printing, U-disk master-making, Ink-saving mode, Pencil mode, Newspaper mode, Screen mode, Book shadow erasure,Programmed Printing,Confidentiality mode, Code mode, Ink used-out reminder, Auto checking the original, Energy-saving function, Print contrast adjustment, The original scanning adjustment, Stencil length adjustment, Auto shut off, Network printing function, Auto-print pressure adjustment . |
| Optional function | no |
| Power supply | 220~240V/50/60Hz |
| Dimensions (DxWxH) | Using: 1320*720*625mm, Storage: 720*695*625mm |
| Net weight(Kg) | Approx. 108 |
