80ton/125ton/200ton/Punch Machine 110kw/160kw Electric Induction Heating Automatic Hot Forging Machine for Brass Fitting Valve Making

Product Description

Product Description
The hot punching machine uses electromagnetic induction heating medium frequency furnace to heat the material, and uses the punching pressure to form the product in the mold at one time. It can form irregular parts such as spheres, hexagons, cylinders, valve bodies, etc. After adopting this process, the requirements for materials can be lowered, the cost can be reduced, the product can be formed at one time, the process can be reduced, deep holes and porous parts can be formed, the problem of complex parts can be solved, and continuous full-automatic production can be achieved, which improves efficiency. This equipment is an ideal equipment to solve the problems that the cold upsetting process cannot solve, and it is an upgrade and replacement of the hot upsetting process of the punching machine.


Production process
Copper material is cut to the required length through the cutting machine → cut bars are conveyed to the medium-frequency furnace storage bin by a lifting machine → bars are heated in the medium-frequency furnace → the hot forging manipulator selects bars with suitable temperatures and feeds them into the die cavity for forging and shaping → the shaped billets are poured into the shot blasting machine for shot blasting. This completes the processing from copper material to shot-blasted shaped billets.


Product Parameters
Hot forging machine includes a set of hot forging manipulator assembly, a pneumatic press (125 tons, stroke 200-230), a medium-frequency heating furnace, and a lifting machine. As depicted in the diagram, brass bars are cut to the required length by the cutting machine. They are then transported by the lifting machine into the storage bin of the medium-frequency heating furnace. After being heated to the appropriate temperature by the medium-frequency heating, the bars are subjected to temperature screening at the end of the conveyor line. Bars with suitable temperatures, controlled by the PLC, are grabbed by the hot forging manipulator to be accurately placed into the center hole of the lower die of the press for forging. Bars with unsuitable temperatures are directly sent to the scrap trough for recycling and reuse.
Hot Forging Manipulator
The hot forging manipulator, as depicted in Figure 2, is a two-degree-of-freedom Cartesian robot. It utilizes servo motors and screw transmission to achieve rapid and precise movement in both horizontal and vertical directions. It is configured with pneumatic grippers, feeding devices, and precise detection systems tailored to customer specifications for bar size requirements. This configuration ensures smooth bar handling and loading and unloading of workpieces.
100IGBT Ultrasonic Induction Heating Equipment
Specifications
1) Model: GY100
2) Rated Input Power: 100KW
3) Rated Input Voltage: Three-phase 380V±10%
4) Control Method: Constant Current
5) Operating Frequency: 17KHZ-30KHZ
6) Load Sustaining Rate: 100%
7) Dimensions (Length * Width * Height mm): 1200 * 550 * 1100
8) Operating Environment: 2°C - 40°C, free from moisture, dust, oil mist, and corrosive gases
9) Power Consumption: Electricity cost per ton of material is 170 + 30% additional electricity (as one of the project acceptance indicators)

Our Advantages
hot forging machine advantages
1. Production efficiency: 5 to 6 times higher than the punching machine. It can produce 50-100 pcs/min according to different product conditions;
2. Operator: one person operation, saving 5 operators compared with traditional punching machine;
3. Safety: fully automatic production, safe and reliable, no work accidents;
4. Production cost: one set of 60-100kw medium-frequency heating furnace, one set of host machine, saving electricity 30%;
5. Qualification rate: product qualification rate reaches 98%, while the highest rate of punching machine is 90%.
