Biobase China China Class B Manual Table Top Autoclave for Laboratory

Product Description

Table TopAutoclave Class B Series
Introduction:
The pulse vacuum autoclave extracts vacuum and fills steam into the sterilization room for many times to make the sterilization chamber reach a certain vacuum degree, and then fills saturated steam to reach the set pressure and temperature, so as to achieve the purpose of sterilization of the sterilized substance.
Features:
1.Brand-new operation interface: The LCD touch screen can display real-time information such as temperature, pressure, time, operating status, fault alarm, and equipment operating curve, making the sterilization information more intuitive and clear, and it is convenient for users to observe the operating status of the equipment.2.Multiple safety protection devices: automatic over-temperature protection device, multiple control and protection of evaporator, door safety interlock protection, double over-pressure protection device, etc.3.Door structure: BKM-K18/23B autoclave adopts a manual door structure, BKM-Z18/23B autoclave adopts automatic door structure. It is could quick and convenient to operate, and effectively protects the human body and prevents burns.4.Vacuum system: It adopts high-efficiency vacuum system, low working noise, ultimate vacuum can reach more than -80KPa, fast pumping speed, good dryness of items, and more thorough sterilization.5.Diversified procedures: There are fast procedures, encapsulation procedures, rubber procedures, dressing procedures, liquid procedures, liquid customization, solid customization and other procedures, as well as B&D testing, vacuum testing procedures, and appointment procedures.6.High-efficiency air filter: 0.22pm sterilizing high-efficiency air filter, the filtration efficiency is not less than 99.5%, to ensure that the vacuum-breaking air is sterile air, and to avoid re-contamination of sterile materials.7.Recording device: The equipment is equipped with a thermal printer and USB interface as standard, which can record the data of the entire sterilization process in real time.8.Other functions: automatic operation of the whole process of preheating, replacement, heating, sterilization, exhaust steam, and vacuum drying.

Model	BKM-K18B	BKM-Z18B	BKM-K23B	BKM-Z23B
Capacity	18L		23L
Door	Manual	Automatic	Manual	Automatic
Max Designed Pressure	-0.1/0.3MPa
Water tank volume	3.5L
Working Temp.	105~134°C
Vacuum System	High efficiency vacuum pump
Chamber Material	S30408
Atmospheric Pressure	76~106kpa
Ambient Temp.	5~40°C
Standard Accessories	USB/Printer
Power Supply	220V, 50/60HZ (Standard); 110V,60Hz (Optional); Wiring Method: Air switch
Consumption	3kVA
External Size(W*D*H)mm	630*485*450		680*485*450
Chamber Size(mm)	φ250*350		φ250*450
Package Size(W*D*H)mm	810*610*590
Gross Weight(kg)	64		65
