16 Channel 5 in 1 Ahd Tvi Cvi IP Xvr DVR CCTV Digital Video Recorder
| Negotiable | 10 Pieces (MOQ) |
Basic Info.
Model NO.
SE-2816XVR
Compressed Format
H.265
Operating System
Linux
Application
Commercial DVR
Interface Type
BNC/VGA/HDIM
Video Input/Output
4/8/16/32 Channel DVR, 16CH BNC Input
Audio Input/Output
4 Channel
Remote Control
Without Remote Control
Video File Logging Mode
Alarm Recording, Motion Detection Recording, Video Manual, Time Lapse Video
Audio
4CH Input, 1CH Output
Hard Disk Size
up to 8tb Each
HDD Supported
2X HDD
BNC Camera Input
16CH 3MP or 8CH 5MP
Interface
1CH HDMI, 1CH VGA, 2X USB
Compression
H.264, Mjpeg
HDMI Resolution
1920X 1080
IP Camera Input
16CH 3MP or 8CH 5MP
OEM, ODM
Yes, Support Software and Hardware Customised
Customized Logo
MOQ 30PCS
Customized Packaging
MOQ 200PCS
Transport Package
Paper Carton
Specification
360(L)* 262(W)*48(H )
Trademark
SECUMATE, OEM, ODM
Origin
Shenzhen, China
HS Code
8521909090
Production Capacity
20000 Pieces/Year
Product Description
16 Channel H.264 HD Hybrid 5 IN 1 AHD TVI CVI CVBS IP DVRMODEL: SE-2816XVR Support 16ch 3MP AHD/TVI/CVI/CVBS BNC video input+16ch 3MP IP Video input
4CH main stream/16CH sub stream playback
HDMI/VGA simultaneous video output
Support 2x SATA HDDs, up to 6TB each, 2x USB 2.0
4 Channel Audio input, 1 Channel Audio output
8 Channel Alarm input, 3 Channel Alarm output
ONVIF, Slink, I8 private protocol
Multiple network monitoring: WEB browser, VMS, Smart Phone(Fseye)
| VIDEO | |
| Video standard | PAL; NTSC |
| Video compression | H.264 |
| Video resolution | 4MP/3MP/1080p/960p/720p/D1/4CIF/DCIF/2CIF/CIF/QCIF |
| Video input | 16CH*3MP(BNC)/4 main Play 8CH*5MP(BNC1,2,5,6,9,10,13,14)/4 main Play 16CH*3MP(BNC)+16CH*3MP(IPC) 16 Sub-Play/ 1 main Play 8CH*5MP(BNC1,2,5,6,9,10,13,14)+8CH*4MP(IPC) 8 Sub-Play/1 main Play |
| Video output | VGA/HDMI sync output:1920×1080P@60Hz,1440×900P@60Hz, 1366×768P@60Hz, 1280×1024P@60Hz,1024×768P@60Hz,800×600P@60Hz |
| Video bit rate | Self-Define(16-8000Kbps) |
| Image display | 1/4/6/8/9/16/20/25/36 |
| Snapshoot | Support (JPEG) |
| Motion detection | 396 (22*18) surveyed area can be set in every screen and multi-sensitivity adjustable |
| AUDIO | |
| Audio encoding | G.711A |
| Audio input | 4CH |
| Audio output | 1CH |
| Bidirectional talk | / |
| RECORDING& PLAYBACK | |
| Video frame rate | 8CH mode: 5MP@15fps;3MP@10fps;1080P@25fps(PAL)/30fps(NTSC) real-time;720P@25fps(PAL)/30fps(NTSC) real-time; Analog/IPC@25fps(PAL)/30fps(NTSC) real-time. 16CH mode: 3MP@15fps;1080P@15fps;720P@25fps(PAL)/30fps(NTSC) real-time; Analog/IPC@25fps(PAL)/30fps(NTSC) real-time. |
| Record mode | Manual/ Timing MD/Alarm exception/MD or alarm/MD and alarm |
| Playback synchronic | Analog 4CH/hybrid 1CH sync-playback(Main stream) 8CH/16CH sync-playback(Sub stream) |
| Search method | Time, Calendar, Event, Channel |
| Video playback | Start, Stop, Fast play, Slow play, Frame play, Snapshoot, Full screen, Roller amplification time ball precise playback |
| VIDEO BACKUP | |
| Interface | 2 SATA |
| HDD capacity | Single Max. 6T |
| Backup location | Local HDD, Network |
| Backup method | Network,USB storage device,USB recorder |
| NETWORK | |
| Protocol | TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPOE, UPNP, NTP, P2P, Onvif |
| EXT INTERFACE | |
| video input | 16CH BNC port(1.0Vp-p,75Ω) |
| Network interface | RJ45 10M/100M/1000M self-adptive Ethernet port |
| Alarm input | 8CH |
| Alarm output | 3CH |
| RS-485 interface | 1 RS485 port |
| USB port | 2 USB2.0 |
| e-SATA | / |
| GENERAL | |
| Temperature | -10°C ~ 55°C/10%-90% |
| Power supply | DC12V/5A |
| Power consumption | 35W (Without HDD) |
| Unit dimension(mm) | 360(L)* 262(W)*48(H ) |
| Weight | 1.5 Kg |
