12~390tex Fiberglass Quartz Fiber Yarn for High Temperatureinsulation

Product Description

Quartz Fiber Yarn Product Description UNION Fiberglass Quartz Fiber Yarns are assemblies of 7.5 microns continuous fused quartz filaments assembled together and twisted.
It has high purity (SiO2 content ≥99.9%)
They are essentially used for their combined low dielectric properties, high mechanical strength and high thermal resistance.
Our yarns presentation can be single, plied or cabled. Our yarns can be used in many of the standard textile processes:
Beaming/Weaving/Braiding/ Texturizing/Stretch breaking/Multiple winding.
Product Parameters

Specification	Fiber Diameter(μm)	Linear Density (Tex)	Twist(T/m)	Tensile(N/Tex)	Type of Sizing
HH-12	7.5±1	12	50-140	0.5	Epoxy type / epoxy K type
HH-13.5	7.5±1	13.5	50-140	0.55
HH-27	7.5±1	27	50-140	0.64
HH-30	7.5±1	30	50-140	0.65
HH-33	7.5±1	33	50-140	0.65
HH-51	7.5±1	51	50-140	0.68
HH-72	7.5±1	72	50-140	0.68
HH-95	7.5±1	95	50-140	0.71
HH-190	7.5±1	190	50-140	0.75
HH-195	7.5±1	195	50-140	0.73
HH-240	7.5±1	240	50-140	0.71
HH-270	7.5±1	270	50-140	0.72
HH-380	7.5±1	380	50-140	0.74
HH-390	7.5±1	390	50-140	0.72

Product Features Compatible with multiple resin system with fast wet-out
Good chopability and good gathering
Anti-static and no fuzz
Good dispersion and lay-down
Low static, excellent mechanical properties
Excellent mold flow-ability
Outstanding product performance and consistency
High-temperature resistance and heat insulation
Excellent acid-resistance and corrosion resistance
Low dielectric constant
Applications 1. Make fabrics for furnace lining in industrial applications and semicon.
2. High temperature seals.
3. High temperature cables.
4. Filtration at elevated temperature and/or in aggressive environment.
5. Thermocouple insulation.
6. Satellite thermal protection.
7. Insulation in automotive exhausts.
8. Electromagnetic window.
9.Stealth materials with structural performance for Unmanned Aerial Vehicles,Uninhabited Aerial Vehicles,fighters,bombers,ships,submarines,tanks.
10.Ablative materials .
