Excavator Long Reach Boom and Arm with Ce Certificate
| Negotiable | 1 Set (MOQ) |
Basic Info.
Model NO.
Kobelco, Hitachi
Usage
Mining Excavator
Material
Q345b (S355)+Q690d(S690ql)
Boom Length
12000mm
Arm Length
10000mm
Max Dig Depth
16500mm
Max. Extensive Scope
21500mm
Max. Dig Height
18500mm
Folding Height
3400mm
Suit Excavator Tonnage
35ton Ecavator
Transport Package
Bubble Film
Specification
CE, SGS, ISO9001: 2000
Trademark
GD-Haide
Origin
Dongguan City, Guangdong Province
HS Code
843149
Production Capacity
1000set/Year
Product Description
Excavator long reach boom and arm(1)Specifications and Standard Supply:
| Long boom | One unit | Long arm | One unit |
| Bucket cylinder | One unit | Standard bucket | One unit |
| pins | 8 units | "H" linkage | One set |
| High pressure hoses | 4 units | Steel tube | 4 units |
| Boom cylinder | Use original cylinders | Arm cylinder | Use original cylinder |
(2)Working Dimension:
| Model | LDB120 | LDB200 | LDB220 | LDB200 | LDB300 | LDB350 | LDB400 | LDB450 | |
| Total length (mm) | 13000 | 15380 | 15380 | 18000 | 18000 | 20000 | 22000 | 24000 | |
| Weight (kg) | 3000 | 4000 | 4200 | 4900 | 5200 | 6000 | 6500 | 7000 | |
| B | Max dig depth (mm) | 9000 | 11340 | 11370 | 13000 | 13000 | 15000 | 16500 | 18000 |
| A | Max extensive Scope (mm) | 12500 | 15100 | 15100 | 17500 | 17600 | 19600 | 21600 | 23600 |
| C | Max dig height (mm) | 11300 | 12510 | 12610 | 13720 | 13720 | 14920 | 16100 | 17300 |
| D | Folding height (mm) | 2900 | 2980 | 3040 | 3210 | 3210 | 3210 | 3400 | 3400 |
| Bucket volume (m3) | 0.3 | 0.4 | 0.4 | 0.4 | 0.4 | 0.5 | 0.6 | 0.6 | |
| Excavator Tonnage(ton) | 10-16 | 20-22 | 22-25 | 20-25 | 30 | 35 | 40 | 45 |
(3)Features:
1.Material :
A.)All Q345B Steel for standard long reach boom.
B.)Heavy duty long reach and excavator tonnage above 40ton :The top and bottom use Q690D steel,Other use Q340B steel.
Q345B steel same as S355 steel in Europe.
Q690D steel same as S690QL steel in Europe.
2.Internal view(spaced by vertical and horizontal reinforcement plate at regular interval)
3.All steel plate are beveled by beveling machine before welding.
4.Welding:
A.) Welded with mixed gas between argon and carbon dioxide. Argon content:80%.Carbon dioxide content:20%.
B.) Welded by robotic welding machine .
