Manufacturer High Quality Aluminum Profile for CNC

Product Description

Product Range:
Everything about aluminum --- Best price, high quality and good service!
Aluminum, aluminum extrusion, aluminum windows, sliding doors, casement doors, hanging windows, curtain walls, railings, curtain walls, fence, handrails, stair tread aluminum, aluminium, aluminum tube, aluminum pipe, aluminum ladder, aluminum trailer, horse trailer, aluminum table, aluminum bench, aluminum goods shelf, aluminum curtain rail, aluminum tents, aluminum pallets, aluminum partitions, partitions, European standard aluminum, industrial aluminum, solar mounting, solar panel frame, heat sinks, radiators (flat wide, sunflower, comb type, round, dendritic ) , aluminum ceiling, aluminum automobile parts, aluminum parts, aluminum luggage rack , aluminum car body, aluminum pet cage, aluminum dog cage, lantern, door, lighting column, LED light aluminum profile, aluminum railway parts, pipelines, hoists, dispensers, testing equipment, rail vehicle body manufacturing, light boxes aluminum, aluminum posters frame, aircraft skin, automobile body frame, car beam, rotor, propeller, fuel tank, siding, car subway Bus body parts materials, doors and windows, car engine parts, air conditioners, body panels, wheels and ships timber, aluminum containers, pipelines, aluminum production line, aluminum baby carriages, aluminum tent pole, etc.
We not only produce Aluminum Extrusion, but also manufacture Aluminum Finish Product with workshops for design, assembly and installation of window, door and curtain wall.
Main Product:
1. Aluminum Extrusion:
Aluminum tube/pipe/angle
Aluminum for window & door
Aluminum for cabinet & wardobe
Aluminum for heat sink
2. Aluminum Finished Product:
Aluminum Door: Insulated/French/Sliding/Entrance/Bi-folding door & Door frame, etc
Aluminum Window: Insulated/awning/Bi-fold/Casement/Louvers/Sliding/Fixed Window,Sunroom & garden Window, Single & double hung window, etc.
Aluminum Roof Lantern & Sky Lights, Curtain Wall, CladingCabinet & Wardrobe, Shutter or Louvre, Handrail and Fence
More Information:
1.Material: Aluminium alloy 6063, 6061,6082.
2.Temper: T5, T6.
3.Quality standard: DIN; AAMA; AS/NZS; CHINAGB.
4.Surface treatment: Mill finish, anodized, powder coated, wood grain, polished, brushed, electrophoresis, etc.
5.Color avalilable: Anyone is available based on your color samples.
6.Packing details: Shrinking film; Plastic & kraft paper; Wooden pallet
Carton packing; By customer's requirements.
7.Samples Time: Normally, 1-2 weeks after receiving molding fee.
8.Delivery: 25-30 days for mass production.
9.Production Capacity: 6000MT/Month
10.MOQ: It's based on the drawings. Basically, it's 2 tons.
11.Port: Guangzhou, Fuzhou; Xiamen; Shanghai; As per requested.
Aluminum Extrusion:

Alloy	6063	6061	6060	6005	6082	6463	7075
Temper	T5	T6	T4
Standard	DIN	AAMA	AS	China GB
Certification	ISO9001:2008
Surface Finish	Mill Finish, Anodized, Powder coated, Wood Grain, Electrophoresis, Polished, Brushed, Fluorocarbon spray-painting, wood grain, hairy,sand blasting, etc
Color	Anodizing	Silver, bronze, champagne, titanium, nickel, golden yellow, etc
		Anodizing thickness is up to 25μm
	Powder Coating	White, black, bronze, grey, green, etc
		Powder coating thickness is more than 60μm
	Wood Grain	1. Italian MENPHIS transfer printing paper
		2. AKZO NOBEL INTERPON D1010 (10 years warranty): Australia ceder, Bush cherry, Chest nut, Jarrah 1, Jarrah 2, Western red ceder, etc.
		3. AKZO NOBEL INTERPON D34 (5 years warranty): Bush wood, Western red, Jarrah, Snow gum, etc.
	Electrophoresis	Silver,nickel, golden yellow, black, champagne, etc
	Polishing	Silver,nickel, golden yellow,black, etc
	Brushing	Silver, nickel, golden yellow, black, bronze, etc
Standard	ISO9001, ISO14001, SGS, OHSAS 18001 Australian Standard: AS US Standard: AAMA2603,AAMA2604, AAMA2605, ETL UK Standard: BS6496 Japanese Standard: JISH4100,JISH8600, JISH8602
Performance	Weather proof, durable, easy cleaning, excellent fire egress, energy efficient glass and 10 years guarantee
Sample time	1-2 weeks after receiving the mold fee
Lead time	25-30days after receiving deposit
MOQ	1 ton
Loading port	Guangzhou, Shenzhen, Foshan, Xiamen, Shanghai, or as per request
Machining	Cutting, punching, drilling, bending, weld, mill, CNC, etc
Packing	Protective film + kraft paper / EPE foam (as per request)
OEM customized aluminium profiles are available.

Mechanical Properties of Sections Under Room Temperature

Alloy	Temper	Tensile Strength Test				Hardness test
		Thickness (mm)	Tensile Strength RM(N/mm2)	Non-proportional Stretching Stress Rp0.2(N/mm2)	Stretching Rate A50mm(%)	Pattern Thickness(m)	HV	HW
6061	T4	All	≥180	≥110	≥16	-	-	-
	T6	All	≥265	≥245	≥8	-	-	-
6063	T5	All	≥160	≥110	≥8	≥0.8	>=58	>=8
	T6	All	≥205	≥180	≥8	-	-	-
6063A	T5	≤10	≥200	≥160	≥5	≥0.8	>=65	>=10
		>10	≥190	≥150	≥5
	T6	≤10	≥230	≥190	≥5	-
		>10	≥220	≥180	≥4

Chemical Composition of Aluminum Alloy
Alloy	Si	Mg	Fe	Cu	Mn	Zn	Cr	Ti	Impurity		Al
									Unit	Total
6063	0.2-0.6	0.45-0.9	< 0.35	< 0.1	< 0.1	< 0.1	< 0.1	< 0.1	< 0.05	< 0.15	Surplus
6061	0.4-0.8	0.8-1.2	< 0.7	0.15-0.4	< 0.15	< 0.25	0.04-0.35	< 0.15	< 0.05	< 0.15	Surplus
6060	0.3-0.6	0.35-0.6	0.1-0.3	≤0.1	≤0.1	≤0.15	≤0.05	< 0.1	< 0.05	< 0.15	Surplus

Adodizing Quality
Grade	Corrosion Resistance			Abrasive Resistance
	CASS test		Alkaline dropping test	Sandtrial Abrasion coefficient f,g/um
	Hours	Grade
AA10	16	≥ 9	≥ 50	≥ 300
AA15	32	≥ 9	≥ 75	≥ 300
AA20	56	≥ 9	≥ 100	≥ 300
AA25	72	≥ 9	≥ 125	≥ 300

Company Strength:
1. Company with rich manufacturing experienc
Brilliance Group Corporation (Guangdong Guang Yin AsiaAlum Factory Co., Ltd),is one of the leading aluminum manufacturer in China, with 26 years experience.
2. Production Management
AAG made complete quality management program and system, Monitor the process from product development, purchasement, production, sales and aftersale service. We passed OHSAS18001,Norway Det Norske Veritas (DNV/ISO9001),British BSI-ISO/TS16949, China GJB900IB, etc.
3. Quality Supervision
AAG own complete testing equipment from raw material to finished products. We own the most powerful curtain wall testing base in China, we passed CNAS, ISO/IEC17025 certificate of authorization, made us be able to offer you accurate,overall,scientific testing datas to our client.
4. Factory Capacity:
Die Center
CNC cutting: 16 sets
CNC lathe: 7 sets
CNC machining center: 15 sets
heat treatment furnace: 3 sets
CNC EDM: 14 sets.
accuracy can be 0.005-0.001mm.
Extrusion Lines
Extrusion lines: 44 sets imported from Japan,Italy with annual capacity 400 thousands of tons.
Anodizing Lines
With 5 full-automatically horizontal type and 1 vertical type.
The oxidize aluminum materials length is up to 10m, electrophoretic materials length is up to 7.5m, with an annual output of 150,000tons.
Liquid Coating Lines
With 6 powder coating lines from Italy, 2 vertical spray-coating lines from USA. The longest aluminum profile can be coated is 11m, with annual capacity uo to 250,000 tons.
Powder coating lines
With 9 powder coating lines from Italy and 4sets of guns from Switzerland.
Our Advantages:
1. 22 years' experiences of manufacturing, 12 years' exporting experiences as ****** GOLDEN SUPPLIER.
2. STRONG R&D: Help customers finalize the design, strong tool design ability,excellent pressing and surface treament technology.
3.Strict quality management: ISO Administration system.
4. 24 hours on-line communication.Professional, Patient, Flexible.
5. High capacity of manufaturing and wide range of products.
6. Be able to provide secondary fabricating.
7. Small order isaccepted.
8. Be able to provide one-stop supply solution.
9. Multiple payment methods: TT, LC. DP,OA.
FAQ to Save Your Precious Time:
Q1: What's the thickness for anodizing? Can you do 25um?
A: Our normal thickness is about 10 um. Yes, we can do 25um.
Q2: What color you can do for powder coating? The thickness for powder coat?
A: We can do any color for powder coat as long as you can provide the color sample. Our normally powder coating thickness is 60-80um.
Q3: What color you can do for wood grain?
A: Our most popular colors are Western Red Cedar, Australia Cedar, Jarrah I, Jarrah II, Chestnut, Bush Cherry, Bush Wood, Western Wood, Snow Gum, etc. If you need any other colors, we can do according to the color samples you provide.
Q4: How's the weather resistance for wood grain finish D1010?
A: (1). Powder: Akzo Noble Interpon D1010.
(2). Wood grain film: Italian Menphis.
(3). Standard complied: American AAMA Standard.2603
(4). UV test:1000 hours.
(5). Salt spraying test:1000 hours.
(6). Normal weather: 10 years color guarantee.
Q5: What's the payment terms?
A: Usually by T/T, 30% deposit and the balance paid before shipment.
Q6: What certification do you have? What's your standard?
A: We have ISO certification. Our standard is DIN, AAMA, AS/NZS, China GB.
Q7: What's the delivery time for samples and mass production?
A: (1). 2-3 weeks to open the new moulds and make free samples.
(2). 3-4 weeks after receipt of deposit and confirmation of the order.
Q8: What's the packing way?
A: Commonly we use plastic film and kraft paper, also we can make as per customers' requirements
