Construction Machinery Luqing New 6 Ton Mini Digger Crawler Loader Excavator Lq65
| US$1,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Diesel
Bucket Capacity
0.21m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Engine Model
Kubota V2607
Power/Rotation Speed
42.4kw/2000rpm
Overall Dimension (L*W*H)
5940mm*1880mm*2570mm
Maximum Travel Speed
2.5/4.2km/H
Swing Speed
0-11 Rpm
Max. Grade Ability
35 Degree
Machine Weight
6500kg
Max. Digging Height
5499mm
Max. Dumping Height
3854mm
Max. Digging Depth
3808mm
Max. Digging Radius
6128mm
Min .Swing Radius
1689mm
Ground Clearance
700mm
Track Length
2580mm
Color
Customized
Transport Package
No Package
Specification
LQ 65
Trademark
Luqing
Origin
Qingzhou, Shang Dong, China
HS Code
84295212
Production Capacity
1000
Product Description
Brief Indruction 1. Full imported hydraulic system ensure the stable quality.2. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency
3. Original Kubota engine,high efficiency low noise.
4. Equipped with double fuel filter to guarantee fuel purity to protect engine
5. Extend hydraulic line for various attachments.
6. Full sealed cabin with A/C and comfort seat make operator easy to work.
7. Intelligent control electric system.
8. Open covering parts makes the maintenance easy to proceed.
Basic specifications
Engine
| Model | Kubota V2607 42.4KW/2000rpm | |
| Type | Direct injection, water cooled, supercharge | |
| No. of cylinder | 4 | |
Main Performance
| Swing Speed | r/min | 0-11 |
| Traveling Speed | km/H | 2.5~4.2 |
| Grade ability | % | 70(35°) |
| Traveling Tracking Force | kN | 30.8 |
| Bucket Digging Force | kN | 48 |
| Arm Digging Force | kN | 35 |
Hydraulic System
| Hydraulic system working pressure | Mpa | 28 |
| Hydraulic Pump | Rexroth | |
| Swing Motor | Eaton | |
| Main Valve | Husco | |
| Fuel Tank Capacity | L | 105 |
| Hydraulic Tank Capacity | L | 90 |
Overall Dimensions
| Overall Length | mm | 5940 |
| Overall Width | mm | 1880 |
| Overall Height | mm | 2570 |
| Ground clearance | mm | 700 |
| Track length | mm | 2580 |
| Track width | mm | 400 |
| Undercarriage width | mm | 1880 |
| Undercarriage ground clearance | mm | 353 |
| Dozer Blade | mm | 1880×350 |
Operation parameters
| Operation Weight | KG | 6500 |
| Bucket Capacity | m3 | 0.21 |
| Max. Digging Radius | mm | 6128 |
| Max. Digging Depth | mm | 3808 |
| Max. Digging Height | mm | 5499 |
| Max. Dumping Height | mm | 3854 |
| Max. Dozer Cutting | mm | 474 |
| Max. Dozer Lifting | mm | 376 |
| Tail Swing Radius | mm | 1689 |
| Sprocket to Idler | mm | 1990 |
DIAGRAMMATIC DRAWING:
CONDITIONS:
QUOTATION TERMS: Based on FOB Qingdao or Tianjin port. 30 days validity since issuing date. PACKING DETAILS: 4 pcs in 20GP container. 8 pcs in 40GP container. Bulk cargo or RO-RO Nude DELIVERY TERMS:
Generally, 20 days after receiving deposit/confirmation; Specific dates shall be confirmed
when order.
PAYMENT TERMS:
By T/T: 30% as deposit and the balance paid after finishing production before shipment
ACCESSOORIES:
Tools box, operator's manual and a list of spare parts.
WARRANTY:
Generally, 6 months or 1000 hours since first receiving the goods, whichever first
ORIGINAL: China
OPTIONAL ATTACHMENTS: Breaker Log grapple Auger
