China Manufacture Car Winch Trailer Winch

China Manufacture Car Winch Trailer Winch

US$59.00-199.00 1 Piece (MOQ)

Basic Info.

Type
Electric Winch
Power Type
Series Motor DC
Pull Direction
Forward
Manual Winch Type
T10
Electric Winch Model
ATV
Working Voltage of Electric Winch
Low Voltage
Hydraulic Winch Type
High Pressure
Brand
Rayvanbo
Applicable Environment
Car
Product Name
Car Winch
Rope Length
6m/ 10m/ 20m /24m
Lashing Capacity
2000lb-16800lb
Color
Black or Customized
Voltage
DC 12V or 24V
Ratio
153:1 / 136:1/164:1/265:1/358:1
Drum Size
1.25"/1.45"/2.52"
Control
Remote Switch
Application
ATV/UTV, Car
Power Source
Electric
Clutch
Turning 180°
Rope Type
Wire Rope/Single Rope or Double Rope
Usage
Cable Pulling Machine
Material
Steel
Brake
Automatic
Transport Package
Carton
Specification
2000lb-16800lb
Trademark
RAYVANBO
Origin
China
HS Code
84253190
Production Capacity
30000 Pieces/Month

Product Description

Product Description
Specifications:
DC 12V Car Winch, mini 12v or 24v electric winch:
1. Capacity: 2000-15000lbs
2. Sling type: wire rope
3. Voltage: DC 12v or 24v DC 12V Car Winch, mini 12v electric winch Introduction:
DC 12V/24V Car Winch is the most common winch, driven by vehicle's own power system. It works in such a way that converting automobile engines power into electricity power to drive the motors and drag noose. It enlarges the output power by the inside planetary reducer to achieve deceleration & torsion enhancement and pull cargo.

Product Features:
It is generally installed in the middle of the front car and connected with the car frame, exposed or hidden in the bumper.
Winch traction is valued by pound which can be converted to ton or kilogram. Do not exceed the rated traction.
The more cycles of winch wire rope on the reel, the less pull the outer cycle to bear.
The best advantage is that it can be normally used in condition of vehicle switch off while others can not.
Easy and multi-position installed, fast movable.
High density & high strength wire rope, durable and firm.

Product features:1.12/24V volt series wound motor for power and fast line speed2. Low-profile design will fit suv, offroad, jeep and so on3.Durable, smooth, and reliable three-stage planetary gear train4. Automatic load-holding break for safety5. The clutch allows you to release winch rope by hand6. Aircraft grade wire rope, or synthetic rope is optional7. Remote switch + wireless remote control8. We have 100% testing on winch pulling capacity and function9. Our products are of well-designed, beautiful appearance and easy to install Product Details
Product Application
Packaging & Shipping
Packaging & Delivery:
Packaging Details: carton or wooden case Delivery Detail: 15 days after received the deposit

Product Parameters
Model Lashing Capacity Rope length Rope diameter Voltage Ratio Drum size Weight
2000lb 2000lb 6m 4mm DC 12v or 24v 153:01:00 1.25" 6.5kg
3000lb 3000lb 6m 5mm DC 12v or 24v 153:1 1.25" 7kg
3500lb 3500lb 10m 5.4mm DC 12v or 24v 153:1 1.45" 9kg
4000lb 4000lb 10m 6mm DC 12v or 24v 136:1 1.45" 10kg
4500lb 4500lb 10m 6mm DC 12v or 24v 136:1 1.45" 12kg
6000lb 6000lb 20m 6.4mm DC 12v or 24v 164:1 2.52" 28kg
9500lb 9500lb 24m 8.3mm DC 12v or 24v 265:1 2.52" 37kg
12000b 12000b 24m 9mm DC 12v or 24v 265:1 2.52" 38kg
16800lb 16800lb 24m 10.5mm DC 12v or 24v 358:1 2.52" 56kg
About Us
FAQ Q1: What are you? Trade Company or manufacturer?
We are both manufacturer & trading company

Q2: What's the advantage of your company?
We've experienced manufacturer and overseas dealer. Our products have been exported to over 110 countries.
An independent research team especially focusing on crane and hoist design upgrade. A professional service
team for customers will provide feedback within 24 hours.

Q3: What's the sample & MOQ to your company?
Sample order MOQ can be 1 set and the product you ordered will be sent in a week as long as inventory is available.

Q4: Can I customize the product according to my own willing?
Yes, OEM/ODM are available, we can customize as customer's request.

Q5: How is the package during transportation?
Composite wooden crate for the electrical parts, waterproof cloth for the steel structure, then packed in a metal crate.
