1530 Carousel 3D Wood Cutting CNC Machine Woodworking Equipment CNC Router
| US$17,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
A4-1325-L8
CNC or Not
CNC
Voltage
220V
Model
Sign-2040
Size
2000*4000mm
Spindle Height
200mm
200mm
Vacuum Table
Max. Power Consumption
2.0kw
Max. Working Speed
25000mm/Min
Spindle Power
9.0kw Hqd
Spindle Speed
0-24000rpm
Drive Motors
Yaskawa Servo Motor
Control System
Syntec 6MB
Transport Package
Wooden Package
Specification
13 cubic meter package
Trademark
SIGN-CNC
Origin
China
HS Code
8465990000
Production Capacity
1000set/Year
Product Description
heavy duty 1530 carousel 3d wood cutting cnc machine 1325 cnc router woodworking equipment cnc drilling machineSpecification
| Model | SIGN-2040 |
| X, Y Working size | 2000*4000mm |
| Z feed Height | 300mm |
| Table Surface | Vacuum table |
| X, Y Structure | Rack and Pinion Drive, TBI Linear Square Guide Rail |
| Z Structure | TBI Linear Square Guide Rail and Ball Screw |
| Max. Power Consumption | (Without spindle) 2.0Kw |
| Max. Rapid Travel Rate | 33000mm/min |
| Max. Working Speed | 25000mm/min |
| Spindle Power | 9.0KW HQD ATC spindle |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Yaskawa servo motor and driver |
| Working Voltage: | AC220V/50/60Hz |
| Command Language | G code |
| Control System | SYNTEC 6MB |
| X,Y,Z repositioning Accuracy | ±0.01mm |
| X,Y Resolution | <0.01mm |
| Software | Artcam |
| Running Temperature | 0 degree - 45 degree |
| Relative Humidity | 30% - 75% |
| Optional Parts | Rotary system, Panasonic Servo motors |
Jinan Sign CNC Equipment Co., Ltd.
FAQ
1. How can I run it ?Send you the operation video and English instruction for use.We provide free technical support 2. What else I need except the machine?computer for design drawing ,ATC machine use air compressor3.What is the warranty?2 years.4. What is your payment?T/T 30% deposit ,70% before shipping.
