Konecranes 1000kg Fixed Type Electric Chain Hoist for Workshop or Warehouse Crane

Konecranes 1000kg Fixed Type Electric Chain Hoist for Workshop or Warehouse Crane

US$2,000.00-8,000.00 2 Sets (MOQ)

Basic Info.

Model NO.
CLX25 04 4 10T 4
Application
Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
Type
Chain Hoist
Sling Type
Chain
Lift Speed
2~8m/min
Maximum Lifting Height
<20m
Chain Falls
One/Two
Certification
ISO9001:2000
Condition
New
Color
Red
Working Level
M4 M5 M6
Standard Lifting Height
4m
Control Voltage
24V
Control Method
Pendent Control or Remote Control
Feature
Portable, Light Weight, Waterproof
Shell
Aluminum Alloy
Core Components
Motor, Bearing, Gearbox
Usage
Lifting Materials
Transport Package
Wooden Case Packaging
Specification
125kg-10t
Trademark
Konecranes
Origin
China
HS Code
84251100
Production Capacity
1000sets/Year

Product Description

Konecranes European Fixed Type Electric Chain Hoist for Lifting Materials
Konecranes hoist is a series of electric hoist products produced by Konecranes Group whose products are widely used in the world.

Product Description

Widely applicable scenarios
Suitable for daily material handling. It is very suitable for material handling work that is not heavy load but is laborious to handle manually. It can be used in various scenarios such as workshops, workstations, bridge cranes or cantilever cranes.
Excellent performance Has a high-quality crane core/ Adopts a sturdy aluminum alloy housing. The lifting speed is optional. The protection level reaches IP55,. Has a high working level and can be started 300 times per hour to meet the needs of frequent use.

Safe and reliable
Equipped with safety devices such as hoist limit switches, safety brakes, and hook trolleys to ensure the safety of operators. The new chain transmission reduces the pressure on the chain, reduces the wear and failure risk of the chain, and at the same time extends the service life of the chain
C series chain electric hoist
Intelligent and efficient: It is the new generation of chain electric hoist of Konecranes. It is built with the lifting core components of Konecranes Group. It is intelligent, durable, accurate and reliable, and the design service life exceeds 1 million times.
Detailed Photos

Product Parameters

Lifting Weight Model working level
Fem/Iso
Lifting speed
m/min
number of chains
1/2/4
125kg C02 P 08 1 012 6 3m/M6 8/2 1
160kg C02 P 08 1 016 6 3m/M6 8/2 1
250kg C02 P 08 1 025 5 2m/M5 8/2 1
320kg C05 P 08 1 032 5 2m/M5 8/2 1
500kg C05 P 08 1 050 5 2m/M5 8/2 1
630kg C10 P 08 1 063 6 3m/M6 8/2 1
1000kg C10 P 04 1 100 5 2m/M5 4/1 1
1250kg C10 P 04 1 125 4 1Am/M4 4/1 1
1600kg C10 P 04 2 160 5 2m/M5 4/1 2
2000kg C10 P 04 2 200 5 2m/M5 4/1 2
2500kg C10 P 04 2 250 4 1Am/M4 4/1 2
3200kg CLX16 04 2 320 5 2m/M5 4/0.7 2
4000kg CLX25 04 2 400 6 3m/M6 4/0.7 2
5000kg CLX25 04 2 500 5 2m/M5 4/0.7 2
6300kg CLX25 03 3 630 4 1Am/M4 2.7/0.4 3
7500kg CLX25 03 3 750 4 1Am/M4 2.7/0.4 3
10000kg CLX25 04 4 10T 4 1Am/M4 4/0.7 4


If there is a demand, please inform us of the following data. We will select a suitable model for you according to the actual working conditions.
Lifting Weight
kg
Lifting Height
m
Lifting Speed
m/min
Are there any special requirements?
Voltage
v
Other
Requirements


Other Products

Certifications

Company Profile
Office Scenarios

Workshop
Inventory of hoists
FAQ
Q 1:What type of company are you?
We are the brand owner of multiple series of cranes, and our brand is Premunk. We also act as an agent for hoists of other brands, such as Konecranes, Dmg and Brima. In addition, we can provide OEM/ODM manufacturing services for our clients. Clients of all kinds are welcomed to come for business negotiations.
Q 2: What trade terms and currencies can you accept?
We normally trade with our clients in EX-Works, FOB, CFR and CIF.We quote prices in Chinese Yuan or US dollars.
Q 3: How about the lead time?
Within 10 to 45 working days after receiving the advance payment.
Q 4: How about the transportation?
We will suggest you the best shipment method according to your goods dimensions and weight. It also depends on clients' decisions. We will try our best to serve you.Suzhou, where our company is located, is close to Shanghai. Therefore, we usually use the port of Shanghai to export goods.
Q 5: Are you responsible for equipment installation?
Regarding installation, the installation service fee is not included in our quotation. We will provide installation instructions to help customers install the equipment by themselves. If customers need us to send technicians to conduct the installation service, we will charge an additional installation fee.
Q 6:What are your after-sales services?
We offer a one-year quality guarantee for our products. If there are any quality problems with the products themselves within one year after shipment, we will provide replacement parts for you as soon as possible. After one year, we will provide paid spare parts for the entire life cycle of the products.
