Plastic Bottle Blowing Machine Blow Moulding Machine for Oil Bottle

Plastic Bottle Blowing Machine Blow Moulding Machine for Oil Bottle

US$4,500.00
1-2 Sets
US$4,300.00
3-4 Sets
US$3,900.00
5+ Sets

Basic Info.

Model NO.
DEG-5L
Raw Material
PET
Making Method of Parison
Stretch Blow
Automation
Non-Automatic
Computerized
Computerized
Certification
CE
Key Words
Blow Moulding Machine
Mould Cavity
1
Bottle Neck
18-120mm
Bottle Size
100-6000ml
Output
300bph (5L), 900bph (500ml)
High Air Compressor
1.2m3/3.0MPa
Low Air Compressor
1.6m3/1.0MPa
Mould Chiller
3HP
After-Sales Service Provided
Engineers Available to Service Machinery Overseas
Transport Package
Wooden Cases
Specification
850kg
Trademark
Degree
Origin
Taizhou, Zhejiang, China
HS Code
8477309000
Production Capacity
100 Sets/Year

Product Description

Product Description

What is pet botttle blow molding machine?
pet botttle blow molding machine is one kind of two step stretch type bottle making plant.
pet botttle blow molding machine is suitable to produce plastic bottles based on PET raw material.
pet botttle blow molding machine is widely used to produce carbonated soft drinks
bottles, mineral water bottles, cooking oil bottles, medicine bottles, cosmetic bottles, wide mouth Jars and hot filling juice bottles etc
Detailed Photos
Product Parameters
MODEL
DEG-5L (One Blower & One Heater)
Clamping Force
150KN
Clamping Stroke
330 MM
Max. Stretching Stroke
440MM
Number of Cavities
1 & 2 Cavity
Theoretical Output
900 BPH(500ml, 2cav), 300 BPH(5L, 1cav)
Max. Mold Thickness
280MM
Voltage Standard
380v/3PH/50Hz
Total Power (Full Loaded)
10KW
Max. Container Volume
6L
Neck Diameter Range
18-120mm
Max. Container Diameter
300mm
Max. Container Height
450mm
Low Air compressor
10Bar
High Air compressor
30-40Bar
Blow molding machine
1850*600*1800mm
Preform Heater
1800*700*1400mm
Net Weight
1000kgs

Certifications
Packaging & Shipping
Company Profile
FAQ
Q1 :What kinds of product you supply?A1: Blow Molding Machine, Extrusion Molding Machine ,Preform Mould ,Cap Mould, Blow Mould,Filling Machine, Packaging Machine, Plastic Products, etcQ2: How to tell your enquiry ?A3: Contact us by email,phone call, fax,instant Messenger (Trade manager , Whats app, Skype) and let us know your inquiry.Q3: How to choose suitable machine?A3: Tell us your requirement, and we will advise you.Q4: Do you have technical support after we purchased your machine?A4: - We will provide video technical support,online support.- If you need,we can also arrange our professional technical to go aboard to your factory,they will help and teach you how to install and maintenance the machine.
