High Speed Paper and Plastic Film PE PP Roll Sheet Cutting Machine

Product Description

High Speed Paper and Plastic Film PE PP Roll Sheet Cutting Machine
Product Feature:
Extruding thickness: 0.02~1.8mm
Productivity: 50~230 Kg/Hr ACCORDING TO THICKNESS and width of the extruding film/sheet.
1. Extruding unit can be moved forward and backward, cooperated with embossing unit fluctuate, which will be more convenient for changing roller and clean the t-die and guarantee operation satety.
2. Italy designed screw enhances plasticizing capability, imported static mixer ensures melting of resins, homogeneous color and increase the quality of the sheets.
3. T-die is from EDI America, which guarantees even thickness and flatness of extruded sheet.
4. Italian made Gearbox has advantages of high efficiency, frictionless and low noise.
5. SCR system is adopted for temperature controling, tolerance of temperature difference is ± 1ºC. This may precisely control plasticizing processes, sheet thickness, flatness and neatness.
6. Microcomputer automatic temperature controlling system precisely controls temperature of embossing roller and cooling roller, so as to make sheet to be flat and neat, keeping the thickness homogeneous.
7. Computer and servo-motor controlled cutting unit guanrantees accurate length and quantity of the sheet.
8. Electric contrl system completely uses international standard with quality, renowned parts and components. And it is synchroized computer comtrlooers to operate the production line safely and conveniently.
This machine is suitable for horizontal cutting of roll materials such as gold and silver cardboard, plain rainbow paper, positioning laser transfer paper, white paper, plastic sheet, aluminum foil, pvc, pet, etc. The electrical main control system adopts central computer control (PLC), man-machine interface operation, dynamic display; fixed-length control is controlled by an imported stepping motor system, and the automatic identification photoelectric switch adopts the function to ensure the cutting accuracy. The whole machine control mode, the speed of the main machine, imported stepping motor, and feeding motor is controlled by the computer to achieve synchronous operation. It has the advantages of high cutting precision, fast speed, convenient feeding, and neat stacking.
Speed: 60 m/min
Size: 3800×1960×1540MM
Product Picture:
Lamination system is available for this unit.
Co-extrusion available for option.
Leading time: 2 months
Product Specification:

Model Number	SYS-PP1300	Film Width	Max 1150MM	Film Thickness	Single Roll:0.08-0.2 Double Roll:0.35-1.6mm
Extruding Capacity	60-230KGS	Screw Diameter	100mm	L/D Ration	1:34
Extruding Motor	75HP AC	Power Supply	120KW	Width Of Embossing Roller	1300MM
Remark	As we continously keep working on research and improvement,we preserve the right to change all of the specifications,design and characteristics on catalogue without notice.
