Ca6250 China Gap Bed Horizontal General Lathe Metal Cutting Machine Machinery
| US$7,600.00-8,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CA6250
Processing Accessory
Metal
Guide Rail
Inclined Guide Rail
Tool Holder
4 Station
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Max. Swing Over Bed
500mm
Max. Swing Over Carriage
300mm
Max. Swing in Gap(Saddle)
720mm
Hole Through Spindle
105mm
Processing Length
750/1000/1500/2000/3000/4000mm
Width of Bed
400mm
Section of Turning Tool
25*25mm
Spindle Taper
Mt6
Taper of Tailstock Spindle Center Hole
No.5 (Mt5)
Spindle Speed
16-1400rpm(24 Steps)
Main Motor
7.5kw
Max. Tailstock Spindle Travel
150mm
Net Weight
2100kg
Gross Weight
2500kg
Packing Dimension
2600*1200*1800mm
Transport Package
Plywood Case with Steel Base
Specification
5.8CBM
Trademark
BST
Origin
China
HS Code
8458190000
Production Capacity
1000/Year
Packaging & Delivery
Package Size
280.00cm * 140.00cm * 190.00cm
Package Gross Weight
2500.000kg
Product Description
Product OverviewProduct Description
-This lathe is suitable for internal and external turning,tapering ,and other rotating faces ,metric,module and inch threads, as well as drilling and pull oil slot .-The lathe bed is 400mm,owns high rigidity,guide face after high frequency quenching,with high durability .-Easy operated ,one handle to operate quite convenient .-Own high rigidity in both structure and transfer parts ,high percent the use of power make the machine cutting easily .
Product Parameters
| Item | CA6150/CA6250 |
| Max. Swing over bed | 500mm |
| Max. swing over carriage | 300mm |
| Max. swing in gap(saddle) | 720mm |
| Effective gap length | 210mm |
| Max. Length of work piece | 750/1000/1500/2000/3000/4000mm |
| Width of bed | 400mm |
| Section of turning tool | 25 x 25 |
| Spindle speed | 16-1400rpm(24 steps) |
| Hole through spindle | 105mm |
| Spindle taper | NO.6(MT6) { Φ113 1:20} |
| Number of feeds | 64 kinds |
| Range of metric threads(kinds) | (1-192mm) 44kinds |
| Range of inch threads(kinds) | (2-24tpi) 21kinds |
| Range of module threads(kinds) | 0.25-48( Module 39 kinds) |
| Range of pitch threads(kinds) | 1-96DP(37 kinds) |
| Max. Tailstock spindle travel | 150mm |
| Tailstock spindle diameter | Φ75mm |
| Taper of Tailstock spindle center hole | NO.5 (MT5) |
| Main motor | 7.5KW |
| Packing Dimension | 2600x 1200 x 1800mm |
| Net /Gross weight | 2100/2200KG |
Detailed Photos
