Siron K000-1 Series NPN PNP Ultra-High Speed Responsive Fiber Optical Amplifier

Product Description

Features * Super power light source combined with high efficiency condenser lens;16us industry super fast response speed
* Equipped with automatic light intensity compensation function;Support multi-language display * High performance organic EL display;Added the optical fiber insertion status indicator Specifications

Name	Ultra-high speed responsive fiber amplifier
Model	K000-1
light source	Red LED (wavelength 660nm)
Operating Voltage	12~30V DC±10%
Current consumption	Standard mode available:52mA(12V)/33mA(24V)/29mA(30V)
	Available energy saving mode: 43mA (12V) /29mA (24V) /26mA (30V)
Output mode	≤100mA, residual voltage less than 1.8V
	Single channel
	NPN/PNP collector open circuit, function switching
Switch mode	L.on (light entry action) /D.on (light blocking action) can be switched
Language	Simplified Chinese/English/Japanese/Korean/Spanish
Circuit stabilization time	300ms
Indicator light	Output indicator (orange)/Power indicator (green)
Display screen	Organic EL display
Response time	16us / 70us / 250us / 500us / 1ms / 2ms /8ms
ON/OFF delay function	ON delay, OFF delay, monopulse output, ON+OFF delay, ON delay + monopulse output(1~30000ms)
Sensitivity regulation	Teaching adjustment/manual adjustment
External input	Teach input/Light stop input/calculator reset input
Operating temperature	-25°C~+55°C
Working humidity	35%~85%RH (non-condensing)
Ambient luminosity	Sunlight exposure ≤10000Lux, incandescent lamp exposure ≤3000Lux
Protection circuit	Overload protection, short circuit protection
Anti-vibration	10~55Hz double amplitude 1.5mm, XZY three directions, 2 hours each
Insulation resistance	>20MΩ(DC500V)
Impact resistance	50G (500m/S²), three times in each direction of XZY
Protection class	IP54
Material	Housing: PPE panel: PC
Outlet mode	2m cable (4 cores)
Weight	71g
