HD3105-43 Durable CNC Milling Machine, Lathe, Machining Center for Industrial Applications

Product Description

Product Description
·One-bed,30° inclined bed, which significantly enhances its machining stability, ensuring precise and reliable performance.
·Equipped with hard rails on all axes, guaranteeing the production of high-quality products with superior vibration absorption.
· Achieves powerful rapid traverse speeds up to (X/Z): 265/730 m/min, boosting productivity.
·Features an optimal lineup of structures, including extended beds, turret punch presses, and servo axes to meet diverse customer needs.
·Compact design with an integrated motor, minimizing machine length in the standard bed style for space efficiency.
·Ergonomically designed for effortless operation and maintenance, ensuring user comfort and efficiency.
Product Parameters

basic specification		Unit	HD3105
Maximum Swing Diameter		mm	φ740
Maximum swivelling diameter of the bed saddle		mm	φ656
Maximum cutting diameter		mm	φ500
Maximum cutting length		mm	708
spindle
Spindle motor power (continuous/30 min)		kw	15/18.5
Maximum spindle speed		rpm	2800
Spindle nose			A2-8
Spindle through-hole diameter		mm	φ91
Bar capacity		mm	φ74
Collet size		inch	12"
feed axis
Maximum stroke X/Z		mm	265/730
X/Z axis motor power		kw	syntec:3.9 fanuc:3
Fast shift speed X/Z		m/min	24/30
X/Z slide type			Box
C-axis (optional )
Minimum spindle positioning accuracy
Dynamic accuracy
turret
Turret Capacity			12
Quadratic cutter		mm	25
Round cutter		mm	φ50
Power Turret Motor Power		kw
Power Turret Tool Specifications
Power tool speed		rpm
tailstock
Mandrel Diameter		mm	φ100
Mandrel Stroke		mm	120
Tailstock body stroke		mm	730
Taper hole taper			MT#5
Programmable Control Mandrel/Tailstock Body			yes/no
Tailstock body movement method			saddle-driven [Programmed
Mechanical specifications
Positioning accuracy (X/Z)		mm	±0.007
Repeat Positioning Accuracy(X/Z)		mm	±0.003
CNC system			syntec or fanuc
chip conveyor			sidebar
Exterior(L×W×H)		mm	3284x1817x1755
Machine weight		kg	5800

Detailed Photos
One-piece bed
Optimized structural analysis
Through sophisticated structural analysis, the main unit structure is optimized to reduce machine height and maintain the bed's dynamic rigidity during heavy machining, even in demanding conditions. The HD-3105's 30° inclined bed further enhances machining stability.
Integrated Cutting Fluid Tank
The cutting fluid tank is strategically mounted at the front of the bed for increased ease of use, while the machine's right side is designed to facilitate the cleaning of ferrous chips.
Hard Rail
The hard rails on all axes absorb vibrations excellently, even during heavy cutting, ensuring the production of high-quality products. The Z-axis, with its long shaft design, delivers exceptional performance, especially in machining long shaft products.
Sealed GIB Construction
The X-axis guideway mounting surface features a sealed GIB structure, which minimizes damage from cutting, thereby preserving the integrity of the X-axis guideway and enhancing durability.
6-sided constrained design improves mobility
Travel X/Y: 265/730 mm ·Spindle Box
The symmetrical design of the box body and the heat dissipation plate structure minimize thermal deformation. The shaft utilizes a combination of tapered roller bearings and angular contact ball bearings, providing robust cutting ability. The 3V belt, being the shortest, reduces vibration and extends lifespan.
Spindle specifications: A2-8 (chuck 12")
Spindle speed: 2,800 rpm
Motor power: 18.5/15KW
