High-Speed Rigid Box Making Machine

Product Description

Zhejiang Xinwei Machinery Co., Ltd. presents the High-Speed Rigid Box Making Machine, an automatic packaging solution for creating custom rigid boxes efficiently.
Performance Introduction
Zhejiang Xinwei Machinery Co., Ltd. - Automatic Mold Adjustment Molding Machine The automatic mold adjustment molding machine is the latest box packaging equipment developed by Zhejiang Xinwei Machinery Co., Ltd. It allows for easy input of the outer dimensions of the top cover on the touch screen, enabling automatic adjustment of corresponding parts such as cornering. This machine also features memory and storage functions, saving time on mold changes.
Structural Features:
Main drive with dual servo drives for stable operation
Flexible and adjustable forming and folding for various carton and paper thicknesses
Widely applicable depth of inner folding paper (10-90mm) without rebound
Bubble-pressing positions with up and down displacement
Pre-adjusted cornering part for different box sizes
Multi-function box-making mode for diagonal, center, and left-right corners
Ejection device with cylinder synchronous operation for smooth ejection

Main technical parameter
Model B420 Book Covering Machine
Model B420 Book Covering Machine Specifications:
Box size max: 450mm x 400mm x 120mm
Box size min: 60mm x 80mm x 10mm
Turn in size: 10mm-90mm
Turn in box height: 90mm
Speed: 0-25P/min
Voltage: 220V 50Hz
Power: 2kw
Air consumption: 10L/min 0.8MPa
Weight: 750kg
Machine dimension: 1500mm x 1200mm x 2000mm
Advantages & Services:
Senior engineers available for service worldwide
One-year warranty with life-long maintenance
Remote monitoring of machines for timely customer support
Continuous innovation for mechanical stability
Customization of non-standard machinery
Payment Terms: T/T, L/C At Sight
Packing Information: All machines packed in Export standard Wooden Box
Why Choose Our Perfect Advance Model Book Covering Machine?
Zhejiang Xinwei Machinery Co., Ltd. is a high-tech enterprise dedicated to research, development, manufacturing, sales, and service. We prioritize technological innovation, quality, and customer satisfaction. With national patents, ISO9001:2008, and CE certification, we ensure high-quality packaging machines. Our customer-centric approach focuses on saving space, labor, and improving economic efficiency.
Contact Information:
Zhejiang Xinwei Machinery Co., Ltd.
Welcome to Zhejiang Xinwei Machinery Co., Ltd. Introducing our top-quality machinery products:
Product Name: Industrial Packaging Machine Our industrial packaging machine is designed to streamline your packaging process, increasing efficiency and reducing downtime.
Features:
- High-speed packaging capabilities
- User-friendly interface
- Durable construction for long-lasting performance
Don't compromise on quality, choose Zhejiang Xinwei Machinery Co., Ltd. for all your packaging needs.
Contact Information: Address: No.555 Jinxiang Road, Feiyun Economic Development Zone, Ruian City, Zhejiang Province, China
