42mm Screw Shaft Stepper Electrical Motor

Product Description

42mm Screw Shaft Stepper Electrical Motor Features
High torque
Low noise
Smallsize
Product Description 2. Specifications:
Motor Model: 42BYGH202-A-41C Step Angle: 1.8°± 5% full step, no load Holding Torque: 220 mNm (31.15 oz-in) Rated Current: 0.5 A DC Motor Length: 34 mm (1.34 in) Shaft End Length: 41 mm (1.61 in) Shaft: Screw Shaft Connectors: Connectors, Lead Wires Ambient Temperature: -24ºC - +60ºC Relative humidity: 90% MAX Resistance Accuracy: ± 10% Insulation Resistance: Larger than 100 mΩ 500 V DC Dielectric Strength: 600 V AC for 1S, leakage current less than 1 mA 2. Notes:
Performance and parameters can be customized, just simply send your motor diagram or samples to us, the competitive price will be sent to you soon for your reference.
Pricing is decided by the motor's performace and parameters, most importantly decided by your requirment, contact us and get the latest the price list. 3. Payment term: T/T in advance, 30% deposit, 70% balance before shipment.

About Zhongshan Shengyang Motor Co., Ltd.:
Zhongshan Shengyang Motor Co., Ltd., established in 2011, has anual production capability of more than 3 million pieces for stepper motor and micro motor. We passed ISO9001:2008 quality system, raw materials comply with RoHS, all of the derived motors can be customized, welcome to contact us.

Contacts: Ms. Rita Law
Mobile: (+86) 13631101993
shengyangmotor.en.made-in-china.com

Series & Length	Model Number	Holding Torque	Rated Current	Resistance per Phase	Inductance per Phase
		mNm oz-in	A	ohm	Mh
42BYGH0 26mm (1.02 in.)	42BYGH001	120 17	0.3	42	48
	42BYGH007	160 22.66	0.4	10.4	14
42BYGH1 33mm (1.30 in.)	42BYGH104	275 38.94	0.4	40	35
	42BYGH107	250 35.40	0.4	22	30
42BYGH2 34mm (1.34 in.)	42BYGH202	220 31.15	0.5	30	37
42BYGH3 40mm (1.57in)	42BYGH312	530 75.05	0.6	26	48
42BYGH4 40mm (1.57 in.)	42BYGH412	420 59.47	1	6.7	9.8
	42BYGH413	300 42.48	1	3.5	5
42BYGH11 34mm (1.34 in.)	42BYGH1101	240 33.98	0.4	30	45
	42BYGH1102	280 39.65	0.84	5.75	9.3
