Product Description

Poultry Farming galvanized House Farm Equipment Suppliers Automatic Poultry chicken
Products Pan Feeders for Broiler and Breeder Product Description
Section-1
Breeder Female Feeding Line include two model:
1) Breeder pan feeding for femal includes Drive Motor, Feed Trough, Chain/auger, Femal Feeder Pan, Hopper, Suspension system and other necessary parts.
2) Breeder chain feeding for femal includes Drive Motor, Feed Trough, Chain, Hopper, Corner and other necessary parts.
3) Auger pan feeding system for male, it includes feed pipe, auger, motor, hopper, suspension system and other necessary parts.
U-BEST select the most stable and quality drive motor to ensure the whole line stable and efficient working automatically. And the chain is from the world top chain supplier Technical System. Feeder could be used from day one, and feeder designed with the maximum feed bearing capacity to supply more birds, meet different growing stage of female. The whole line design aim to get the best FCR.

Breeder Chain Feeding System	Breeder Pan Feeding System
Type: Automatic	Type: Autimatic
Feed conveying ability: 36m/minute, 2.0 ton per hour	No. of birds/pan: 15 Birds
Loop Hopper: 275g/m2 hot galvanized steel hopper with feed return wheel; ZYZJO-220/280/350KG,including cover,block chicken plate	Hooper: 275g/m2 hot galvanized steel hopper with feed return wheel, 280 kgs, including cover,block chicken plate
Corner: High rigid 90° cast- cast- iron,good corrosion and wearing resistance	Feed Pan: Raw PP/360mm diameter, 330-360mm diameter
Motor: Direct drive motor ,1.5kw/2.2kw,,220/380v,50hz	Pan distance: 0.75-1M
Chain: South Africa, . Smooth chain feed conveying	Two Layer design:prevent male birds eating from female feed pan
Hanging system: China top Steel wire, pulley,adjuster,etc.	Motor: Motor 2.2kw, Conveying speed 36m/s
Automatic Egg Nest
Dimension (legs not included )/set	2240*1120*640mm ; 100birds/nest
Nest Quantity/set	16
Width of belt (mm)	100
Delivery speed	6m/min, adjustable
Max Delivery distance	120M
Nest size	320*275mm
Collection mode	two side collection

Section-2
Feed Storage and Feed Fill System include the feed silo, flexible feed delivery auger, PVC feed delivery pipe, drive motor and other necessary parts. It's benifit with simple, high quality and efficiency.

Feed Fill System	75mm	90mm
Max Delivery Length	60m	40m
Gear Motor	1.1HP/1.5HP,50/60HZ, 1 PHASE/3 PHASES	1.1HP/1.5HP,50/60HZ, 1 PHASE/3 PHASES
Delivery Capacity	1400KGS/H	2500KGS/H

Section-3
Nipple Drinking system Includes water pipe, regulator, nipple drinker, drip cup, suspension line, front component, midcator and others.
Section-4Climate Control System Include the tunnel fans, air inlet, cooling pad & tunnel door.
1-Tunnel Fans
Performance

Fan Model	Static Pressure		Air Flow		Motor
	Pa	In.H2O	M3/H	CFM	Voltage(V)	Frequency(HZ)	Phases
54in Fiberglass Cone Fan	0	0	55000	32600	220v-380v	50/60	1 or 3
	12.5	0.05	53100	31300	220v-380v	50/60	1 or 3
	25	0.1	50800	29900	220v-380v	50/60	1 or 3
50in Galvanized Cone Fan	0	0	49530	28465	220v-380v	50/60	1 or 3
	12.5	0.05	40194	23100	220v-380v	50/60	1 or 3
	25	0.1	37236	21400	220v-380v	50/60	1 or 3

2-Curved Air Inlet
Performance

Static Pressure		Air Flow		Air Inlet
Pa	In. H2O	M3/H	CFM	Size(mm)
12	0.05	4050	2383	1100*330
25	0.1	1980	1165	1100*330

3-Evaporative Cooling System
4-Tunnel Door System
a-Special selects panel material for better insulation in different climate conditions
b-Modular panel design allows maximum flexibility in door size to match house sidewall openings
c-Better mixing the fresh cold air and hot air prevent the chicken flock away from the cold stress.
d-No more dead zone at side and end walls
e-Better guide the air flow to the center of the roof
f-Automatic controlled the opening size by the controller in different bird age.
Section-5
Controller & Control Panel The ventilation control system consists of computerized controller, tempreture sensors, humidity sensors, negtive pressure sensor and alarm system.By means of the sensors and preset tempreturers, humidity, and negative pressure, the controller can regulate temperatures, moisture, wind speed and negative pressure in the house.
U-BEST company control panel select the world top brand electronic components,siemens & ABB to ensure safety of the chicken farm.
Part-6 Lighting System-Dimmable
Part-7
Heating system-Damly Brooder and space heater
Part-8
Automatict egg collection system & Manual egg collection nest Galvanized material for egg nest. Part-9
Plastic slat for femal area We choose raw material with high quality and long service life.
Company Profile
Weifang U-Best Husbandry Equipment Company information:
U-best offers a wide range of products with targeted designs according to clients' requirements in
order to satisfy different environmental conditions. U-best will always be producing the state-of-the-art facilities, compounding with professional after-sale service to show all of the world.
Complete broiler poultry equipment also can be provided by us:
1.Main feeding line system
2.Automatic pan feeding line system
3.Automatic nipple drinking line system
4.Ventilation system
5.Cooling pad system
6.Environment control system
7.Heater system
U-BEST breeder farm equipment warranty:
1. All plastic products are made of virgin raw material such as the feed pan , water drip cup ,clips ,
air inlet 15 years
2. Nipples : 10 years
3.The accesorries such as the bolts ,nuts ,pulley ,water winch ,rope clips are stainless steel
4. Feed motors from Italy brand Transtechno
5. Auger from South Africa technical system
6. Feed sensor from Germany
U-BEST could offer you one stop service include:
1-Farm Design Consulting
2-Farm Layout/Design
3-Turnkey Design-Build
4-Steel Building Packages
5-Poultry Equipment Packages
6-Construction Supervision
7-Construction Management Service
8-Bio Security Facilities
9-Organic Fertilizer/Chicken Manure Treatment
10-Feed Processing Facilities & Buildings
