4X8feet Waterproof Plywood Making Machinery/Wood Veneer Peeling Lathe

4X8feet Waterproof Plywood Making Machinery/Wood Veneer Peeling Lathe

US$13,000.00-80,000.00 1 Piece (MOQ)

Basic Info.

Type
Veneer Production Machine
Automatic
Automatic
Certification
CE
Name
Veneer Peeling Machine
Condition
New
Application Field
Plywood Manufacturing Plant
Transportation
by Sea
Delivery Time
Depend on Your Quantity
Size
1300mm 2600mm 2900mm
Voltage
380V/415V /Customizable
Warranty of Core Components
2 Years
Key Selling Points
High Efficiency , Long Service Life
Video Outgoing Inspection
Provided
Project Solution Capacity
Cross Categories Consolidation
Core Components
Bearing , Motor , Gearbox , PLC ,etc
After Sale Service
Online Technical Support
Other Products
Log Debarker, Veneer Stacker , etc
Machinery Test Report
Provided
Transport Package
by Container
Specification
2900mm 3200mm
Trademark
GTCO
Origin
China
HS Code
8465
Production Capacity
100/Month

Packaging & Delivery

Package Size
580.00cm * 300.00cm * 160.00cm
Package Gross Weight
10000.000kg

Product Description

4x8feet waterproof plywood making machinery/wood veneer peeling lathe
Product Parameters
GTRD2600mm Veneer Peeling machine
Length of Log(mm) 970-2700mm
Max Processing Log Diameter Φ550
Min Residual wood Diameter(mm) Φ35
Single and double roll diameter(mm) Single rollerΦ125 , Double RollerΦ125
Working thickness Range(mm) 0.4-4.0
Peeler Blade size (mm) 2900*180*16
Main Line Speed (m/min) 0-80m/min and adjustable
Total Motor Power(kw)
(45KW )
Single Roller : Φ125mm, R87 reducer ,7.5kw*2;
Double Roller : Φ125mm,R87 reudcer,15kw
Feeding motor: R87 reducer, 11kW;
Blade motor: RV120 reducer, 4kw.
Conveyor Motor: RV 120 reducer, 4KW
Overall Size(L*W*H) mm 6200* 2250*1650
Weight (KGS) About 8000KGS

1300mm Veneer Peeling Machine Plywood Making Machine
Wood log max.Dia. 450mm
Left log dia. 30mm veneer thickness
Core veneer thickness 1-3.6mm knife specification
Peeling knife 1400x180x18mm
Overall dimension 3600x2200x1300mm
Weight 4.5tons
Total power 25.5kw

Product Description
1.Working steady : The blade base is fixed . double roller moving and steady the guide rail . increase the working stability and veneer quality . It is also convenient to transfer veneer
2.Reduce wear : Adopt double screw nut , reduce the worn of nut and can adjust the screw gap according to the wearing capacity , promise the machine working in high precision condition
3.Key technology : Special cams structure to adjust the pressure from single roller to log , it is changed according to log diameter , simplicity and strict , keep the pressure and knife gap in the same . This is the key technology for this machine
4. High performance
Adopt high-performance universal coupling , increase the strength and reduce the working noise drastically . not easy to broken
5.Heavy bearing :Adopt heavy bearing , increase the bearing strength and reduce the bearing quantity . so can down the broken risk
Detailed Photos
Packaging & Shipping

Company Profile
WHO WE ARE
GTCO Machinery company is located in Xicheng New District, Linyi City--- a commercial and logistics city.
After more than 20 years' continuous innovation and development , Machinery has become an outstanding enterprise along with strong power , advanced technology and excellent quality Products are sold nationwide , exported to Asia , Europe , Africa and Oceania... etc .
WHAT WE DO
We have strong technical strength, talented people, and constantly introduces various automation and semi-automatic products. Now the national key promotion panel automation transformation production line, plywood production line, veneer machinery .automatic edge cut machine ,veneer peeling production line, veneer dryer, automatic veneer cutting machine, hot press, cold press, lifting platform, automatic putty- scraping machine and glue spreader etc.
2020 years ,we join in the new design and construction machine - stone crusher ,the main product have PE Jaw Crusher, PF Impact crusher , CS Cone crusher Feeder and screen Mobile crusher. etc.
We always right here waiting for service to you !
Welcome to visit us.
WHY CHOOSE US
1.Customized equipment, especially of unusual size, press, etc.
2.High quality and technical support
3.So rich international-trade experience for machinery.
4. 7*24hour on line service.
