Factory Supply Best Price High Performance Low Noise Oil Injected Industrial Rotary Screw Air Compressor (7.5kw -630kw /7bar -13bar/ CE & ISO Passed)

Product Description

Factory Supply Best Price High Performance Low Noise Oil Injected Industrial Rotary Screw Air Compressor (7.5kw -630kw /7bar -13bar/ CE & ISO Passed 1. Product picture :

2.Products details :
3.Product Features:

1) High reliability

• large air end and low speed design

•SKF bearings whose service life for more than 50,000 hours , low wear and long service life

• original imported driven parts: coupling

•More than 30% heat dissipation design

2) Energy saving

• The rotor adopts European and American patent screw type line design, high efficiency, energy saving

• reasonably configure the fan , configure the minimum power on the premise of maximum efficiency

• all standard direct drive units reduce gear configuration to lower energy loss

• each unit is tested by the national energy efficiency laboratory, and each unit is guaranteed to reach the national level

4.Techincal parameter for GREAT brand oil injectted fixed speed driven ( FSD) Screw air compressor :

Model	Flow Air Capacity(m3/min )/Working Pressure(Bar)				Power/ (Kw)	Voltage (V/Hz)	Noise (±3,dBa)	Oil content	Outlet pipe size	Weight (Kg)	Dimensions (mm)
TKL-2F	0.33/7	0.33/8	0.25/10	0.22/13	2.2	380V/50Hz	63	≤3	1/2″	260	800*760*1102
TKL-3F	0.43/7	0.4/8	0.36/10	0.3/13	3		63		1/2″	280	800*760*1102
TKL4F	0.6/7	0.55/8	0.5/10	0.45/13	4		65		1/2″	300	800*760*1102
TKL-5F	0.8/7	0.7/8	0.65/10	0.6/13	5.5		65		1/2″	350	800*760*1102
TKL-7F	1.23/7	1.16/8	1.02/10	0.86/13	7.5		67		1/2″	360	800*760*1102
TKL-11F	1.65/7	1.62/8	1.4/10	1.21/13	11		67		3/4″	400	950*760*1202
TKL-15F	2.7/7	2.5/8	2.0/10	1.8/13	15		68		1″	430	900*1000*1290
TKL-18F	3.0/7	2.92/8	2.7/10	2.2/13	18.5		70		1″	590	belt type900*1000*1290 strait type1350*850*1257
TKL-22F	3.6/7	3.53/8	3.2/10	2.4/13	22		72		1″	650
TKL-30F	5.2/7	5.0/8	4.5/1.0	3.5/13	30		73		1 1/2″	950	1500*950*1280
TKL-37F	6.6/7	6.3/8	5.6/10	4.8/13	37		74		1 1/2″	980
TKL-45F/W	7.8/7	7.5/8	6.8/10	5.8/13	45		75		1 1/2″	1050	1600*1100*1430
TKL-55F/W	10.1/7	9.8/8	8.8/10	7.2/13	55		76		DN50	1850	1900*1150*1500
TKL-75F/W	13.5/7	12.3/8	11.0/10	9.0/13	75		78		DN50	1900
TKL-90F/W	16.3/7	15.6/8	14.2/10	11.5/13	90		78		DN50	2100	2000*1150*1680
TKL-110F/W	20.4/7	20/8	17.8/10	14.5/13	110		78		DN80	300	F 2800*1540*1900
											W 2400*1540*1900
TKL-132F/W	24/7	23/8	21/10	18.1/13	132		78		DN80	3500	F 2800*1540*1900
											W 2400*1540*1900
TKL-160F/W	27.8/7	27.1/8	25.2/10	21.2/13	160		78		DN80	4000	F 3150*1650*1900
											W 2600*1700*1980
TKL-185F/W	32.5/7	30.5/8	27/10	23.6/1.3	185	380-10000V/50Hz	78		DN80	4600	F 3100*1940*2389 W 2600*1700*1980
TKL-200F/W	35/7	33.3/8	30.6/10	26.3/1.3	200		80		DN100	4700
TKL-220F/W	40.7/7	38.2/8	34.5/10	29.8/1.3	220		80		DN100	5100	F 3400*2000*2330 W 3200*1800*2125
TKL-250F/W	45.3/7	43/8	38.1/10	35/1.3	250		80		DN100	5100
TKL-280F/W	51.5/7	50.5/8	43/10	38.3/1.3	280		80		DN100	5500
TKL-315F/W	57/7	55.5/8	50.5/10	42.1/1.3	315		80		DN125	7500	4500*200*2462
TKL-355F/W	68/7	66.2/8	55.6/10	46.5/1.3	355		80		DN125	8300
TKL-400F/W	73.6/7	71.4/8	62/10	52.5/1.3	400		82		DN150	8400	4650*2340*2835
TKL-450F/W	83/7	82/8	73/10	60/1.3	450		82		DN150	9000
TKL-500F/W	90/7	89/8	80/10	68/1.3	500		82		DN150	9600
TKL-560F/W	101/7	100/8	86/10		560		82		DN200	10000
TKL-630F/W	111/7	110/8	95/10		630		82		DN200	10000

5.Application :
6.Certification :
7. Packing & shipping:
8. other related products :
·fixed speed(FSD) screw air compressor
·variable speed(VSD)screw air compressor
·permanent magnet variable speed( PM VSD)screw air compressor
·2 stage compression FSD screw air compressor
·2 stage compression PM VSD screw air compressor
·low pressure screw air compressor
·diesel engine driven portable screw air compressor
·electric motor driven portable screw air compressor
·outdoor use screw air compressor
·oil free screw blower
·integrated screw air compressor for laser cutting machines
9. Company introduction:
Tianjin Great Air compressor Co., ltd, is one leading manufacture and exporter of air compressor in Tianjin, China, Founded 1957 years, coving an area of 200000 square meters. Now exporting to more than 120 countries. Has established a huge sales and service network at home and abroad.

why you choose us ?	1. Over 60 years China professsinal manufacture for air compressor ,An ISO9000 company
	2.European standard,China made &factory directly supply
	3. Superior porformance &high efficiency with reasonable price
	4.Low power consumptions for more output
	5.Trouble free & cost saving
	6.Timely pre-sale and after-sale service
	7.Easy operatation &maintenance

10.FAQ :
Q1: Are you factory or trade company?
A1: We are factory.
Q2: Warranty terms of your machine?
A2: One year warranty for the machine and technical support according to your needs.
Q3: Will you provide some spare parts of the machines?
A3: Yes, of course.
Q4: How long will you take to arrange production?
A4: 380V 50HZ we can delivery the goods within 20 days. Other electricity or other color we will delivery within 30 days.
Q5: Can you accept OEM orders?
A5: Yes, with professional design team, OEM orders are highly welcome!
11. Our service :
11.1 ).After-sale Service
• Any questions or requests before, during or after sales, we would like to help you any time and will find you the best solution in 24 hours.
• Warranty: One year for the whole machine two year for air end , and spare parts will be provided with best price.
• Over board engineer service is available.
11.2). Special Customized Service
1) Full OEM
• Quantity: at least 5 pcs
• In this plan, we will do all the changes (Color, name plate and logo) as your need, and will not charge extra fee.
2) Half OEM
• Quantity: no limit
• Under this program, we can make the necessary alteration (name plate and logo) but we will charge some extra fee for the name plate, as the name plate factory has the MOQ.
3) Logo OEM
• Quantity: no limit
• Only the logo will be changed to yours, and no extra fee will be charged.
11.3). Overseas Engineer Service
• We are available to send our engineer for aboard service. Only need you to arrange the accommodation, transportation and translator. Extra cost for each will be discussed based on local price level.
