Wuling refrigerator box truck for food transportation

Product Description

Product Description
Product Description
The chassis of wuling special purpose vehicle series is from SGMW, a joint venture by GM,Shanghai motors and Wuling motors, it sold 2 million units vehicle all over the world in year 2016 .
We have professional refit vehicle team, and can not only produce large quantities of assembly line products, but design and manufacture customized products according to customers.
Specifications:

Item		LQG5029XLCPY
Size	Dimension (mm)	4705*1615*2370
	Box container(mm)	2450*1415*1455
	Wheelbase (mm)	3050
Weight	Total weight(kg)	2350
	Curb weight(kg)	1530
Passenger Capacity		2
Performance	Min Turning Diameter(m)	11.9
	Overhang (F/R)(mm)	540/1115
	MIN.Clearance(mm)	140
	Max Speed(km)	120
Engine	Displacement(ml)	1485
	Model	L3C
	Rated Power(kw)	79
Refrigerator	Cooling range	—10℃
Fuel Consumption With The Regrigerator Closed(L/100km)		7.5
Fuel Consumption When Refrigerating(L/100km)		11.4
Transmission		Five Speed

Refrigerating unit specifications:

Item	WLQ5029XLCPY
Model	YX-260S
Reefer temperature range	-10℃~+20℃
Refrigerating output(W)	1500W(-10℃)
Driving mode	Driven by engine
Voltage DC(V)	12V
Refrigerant	R404a
Reefer temperature adjusting	Electronic digit display
Safety device	High-low voltage switch safety protection
Defrosting mode	Manual/automatic defrosting

Production line:
Key components:
Our Services
1.WARRANTY
we will provide one year warranty for our truck main parts, such as Engine, Transmission, Axle and Steering system.
2. TECHNICAL SUPPORT
Our rich-experience technical teams are standing by all the time for our vehicle products.
Company Information
The chassis of wuling special purpose vehicle series is from SGMW, a joint venture by GM,Shanghai motors and Wuling motors, it sold 2 million units vehicle all over the world in year 2005 .
