Transfer Machine for Air Conditioning Valve
| US$50,000.00-70,000.00 | 1 Unit (MOQ) |
Basic Info.
Model NO.
MW8G10Z
Application
Glass
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.02~0.03(mm)
Performance Classification
High-End CNC Machine Tools
Certification
GS, CE
Condition
New
Packing Method
Wooden Case Packing
Transport Package
Sea Worthy Packaging
Specification
3.5x2.6x2.8meter
Trademark
MW
Origin
China
Product Description
Example of Aair conditioning globe valve
| Spindle#5,110mm,Taiwan made, Boring or milling | Station #4 | Spindle #6, 110mm.Taiwan made, Groov milling | Station #4 | ||
| Turning motor (servo) 4KW, " Gtake " China, 2800RPM | Feeding motor (servo) 1 KW , " Xinjie " China, less than 2000RMP | Synchronized clamp. Code:CP-40, China made | Turning motor (servo) 3 KW, German threading head ) , 2000RPM | Feeding motor (servo) Y-axis 1 KW, X-axis 0.75KW "Xinjie" China, less than 2000RMP | Synchronized clamp. Code:CP-40, China made |
| Spindle#7,110mm,Taiwa n made, Threading | Station #5 | Spindle #8, 110mm.Taiwan made, Grooving | Station #5 | ||
| Turning motor (servo) 4KW, " Gtake " China, 800RPM | Feeding motor (servo) 1 KW, " Xinjie " China, less than 1200RMP | Synchronized clamp. Code:CP-40, China made | Turning motor (servo) 4KW, " Gtake " China, 2800RPM | Feeding motor (servo) 1 KW (Xinjie " China less than 2000RMP | Synchronized clamp. Code:CP-40, China made |
| Spindle#9,110mm,Taiwan made,drilling | Station #6 | Spindle #10, 110mm.Taiwan made, Threading (int) | Station #7 | ||
| Turning motor (servo) 4KW, "Gtake"China, 2800RPM | Feeding motor (servo) 1 KW,"Xinjie" China, less than 2000RMP | Synchronized clamp. Code:CP-40, China made | Turning motor (servo) 3 KW, " Xinjie " China, 800RPM | Feeding motor (servo) 1 KW," Xinjie " China, less than 1200RMP | Synchronized clamp. Code:CP-40, China made |
This is a multi-station transfer machine, to work for the multi-spot processing needs, complete the machining of the part within very short cycle time through multi-spindles linkage. This demonstration is showing processing of part for sewing machine, fix a slidable power head to fulfile dual holes machining. Its high cost performance and efficient widely used in the mass-production task, and fit for compact workshop condition. The compact structure and amazing cycle time compare to the normal single CNC turning machine or other boring machine, performing huge advantage. It is much easy to customize to user specific requirement on process of the part, flexibly to set power head according to process conversion.
Machine Basic Parameter
| Station Numbers | 8Stations |
| Driving unit numbers | 10Spindles |
| Syntronized Clamp Model | CP-40 |
| Driving Head Motor | Full servo |
| PLC mode | Bus motion Controller |
| Indexing Table | 421-8D |
| HMI | 10" |
| Spindle Size | D110mm |
| Total Power | 62KW |
| Machine Foot print area(ovrall size) M | 3.5x2.6x2.8meter |
| Weight (KG) | 7000 |
