Product Description

Cottonseed oil refinery crude oil refinery for sale
According to different oil seeds, different process methods for crude oil, different requirements for finished products by customer, different capacity and refine ways. The oil refinery is divided into three types: batch oil refinery, semi-continuous oil refinery and continuous oil refinery.
Methods for oil refinery: Mechanism, chemical, and physical.
Main process: Filter, Washing(degumming), Neutralization(deacidification), Adsorption (bleaching), Winterization(dewaxing, stearin removing), distillation (deodorization).
Process Category: depending on the oil seeds and crude oil in the preparation of different techniques, different customer requirements for finished products, the processing capacity of different sizes and different refining methods, the company's refining equipment is divided into three types: batch refining equipment, semi- continuous refining equipment, the whole continuous refining equipment.
Process characteristics:
One, semi-continuous refining equipment features:
1, suitable for small and medium enterprises.
2, for a variety oil seeds of oil refining, which will help users to develop business.
3, independent design for each refining stage, good for expanding the production in the future.
4, low cost, save heat supply source, high output of production oil.
5, high level of refined oil, according to requirements, the user controls the operation of various stages by himself, which makes the finished oil to achieve the desired standards.
6, can provide PLC controlled.
7, disadvantages: high cost of the device.
Two, Main equipment and usage:
1, bleaching section using two automatic slag filter, to improve the continuity of the process.
2,deacidification deodorization tower uses physical methods for taking deacidification and deodorization one time, avoiding loss of refined oil by chemical deacidification.
3, oil/oil heat exchanger, the design is for cooling hot oil by cold oil, while heating cold oil by hot oil, to achieve energy saving and improve efficiency.
4, heat transfer oil furnace and steam boiler are uesd simultaneously, improve oil rate and product oil quality.
Three, Pay attention
1. Preparation of rice bran oil is mostly from the leaching process, and since the storage time of the different raw materials, the acid value is too high, suggest the whole process chooses physical refining, the advantages are low loss with good quality of finished oil. The wax content of crude rice bran oil is 3-5%, so dewaxing process must be configured. The content of fatty acid sodium in soapstock of Rice bran oil is more than 40%, can be used to make laundry soap.
2, The processing methods of palm oil (pulp oil) and palm kernel oil (nut oil) are different, they are two different crude oil, fatty acid composition and physical properties are also different. Refining method is similar, but very different specific operations.
3, the storage time of crude oil should not be too long, to prevent the acid value increased, affecting the quality of crude oil and the oil rate of refining.
Recommended options: the refining process of physical refining, with economic, high efficient and easy to operate, energy saving and easy to handle wastewater and other advantages.
Welcome to inquiry on Cottonseed oil refinery crude oil refinery for sale.

Name	Cottonseed oil refinery crude oil refinery for sale
Capacity	10t/d
Production time	20 days
Package	wooden case, film package
Payment	TT/LC
