High Quality Supplier of Highly Productive Sheet Metal Coil Slitting Machine Cut to Length Line Cutting Machine
| US$120,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BW
Drive Mode
CNC
Warranty
1 Year
Cutting Width (mm)
0 - 9999 mm
Material Thickness(mm)
8 - 20 mm
Cutting Speed(M/Min)
0 - 30 M/Min
Coil Weight (T)
20
Voltage
380V/220V/415V/440V/Customized
Rated Power
260kw
Transport Package
Wooden Case
Specification
2500X1000X20 cm
Trademark
BANGWIN
Origin
China
Product Description
Product DescriptionThis automatic cut to length line is used for uncoiling, leveling, and automatic length measuring and cutting. Electrical controlling by AC variable frequency and servo control, which has better length precision and efficiency.
Application:It is suitable for cut the metal coils to sheets/plates. Advantages:Easy to operate, cut to length quality is high, excellent material utilization, Stepless shearing speed regulation, etc. Structure:It consists of uncoiler, feeding and positioning, cutting unit, stack, etc. Applicable materials:Tinplate, silicon steel, aluminum, copper, stainless steel and galvanized steel, etc.
Product Parameters
| Processing Thickness | 0.5~10mm | Processing Width |
| 600-2000mm | Cut to length Accuracy | ±1.5 mm |
| Cutting Speed | 10-70m/min | Coil Inner Diameter |
| 500/610 mm | Coil Outer Diameter | ≤2000 mm |
| Cut to Length Range | 500~4000mm | Sheet Leveling Flatness |
| ≤±1.5mm/m² | Length tolerance | ≤±1.5mm /2m |
| Diagonal tolerance | ≤±1.2mm/2m | Levelling precision |
| ≤2mm/m2 | Cut length | 500~3000mm |
| Not limited to above mentioned parameters,customzied machine is available. | ||
