Vertical Drilling Machine (Floor Type Drill Press DP5125 DPQ5125 DP5120 )
| US$200.00-1,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DP5125 DPQ5125 DP5120
Controlling Mode
Artificial
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Manual
Precision
Normal Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Drill Capacity
20mm
motor
1100W
spindle taper
MT3
Spindle Travel
120mm
table size
350X350mm
Transport Package
Plywood Case
Specification
100Kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459290000
Production Capacity
50PCS/Month
Product Description
DRILL PRESS FLOOR TYPE
High Rigid Construction
Easy Operation and Extended Durability
Different Sizes and Replaceable Worktables
Considerable Safety Design
| MODEL NO. | DP5125 | DPQ5125 | DP5120 |
| Motor power | 1100W | 750W | 750W |
| Chuck | 20MM | 20MM | 20MM |
| Spindle Stroke | 120MM | 82MM | 82MM |
| Spindle Taper | MT3 | MT3 | MT2 |
| Speed change | 12 | 12 | 16 |
| Speed 50/60Hz | 150-2450/180-2940R.P.M. | 280-2380/340-2860 RPM | 220-2840/260-3410RPM |
| Swing | 438mm 17'' | 360MM 14'' | 360MM 14'' |
| Working table | 350X350 | 290X290MM | 305*305MM |
| Base size | 510X350 | 460X280MM | 460*280MM |
| Column | 92 | 80 | 72 |
| Total height | 1700 | 1600MM | 1580MM |
| Weight | 110/100 | 75/71KG | 73/70KG |
| Packing dimension | 1430X660X330 | 1150X500X300MM | 1150*500*300MM |
| Contact Us: |
Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
